3528 Tri-Color SMD LED RGB PLCC-4 Chip Light Emitting Diode with Black Case for Backlight and Indicator
3528 Tri-Color SMD LED RGB PLCC-4 Chip Light Emitting Diode with Black Case for Backlight and Indicator
3528 Tri-Color SMD LED RGB PLCC-4 Chip Light Emitting Diode with Black Case for Backlight and Indicator
3528 Tri-Color SMD LED RGB PLCC-4 Chip Light Emitting Diode with Black Case for Backlight and Indicator
3528 Tri-Color SMD LED RGB PLCC-4 Chip Light Emitting Diode with Black Case for Backlight and Indicator
3528 Tri-Color SMD LED RGB PLCC-4 Chip Light Emitting Diode with Black Case for Backlight and Indicator
Specifications
Brand Name :
BOSMFC
Model Number :
3528 SMD LED
Certification :
Rohs, Reach
Place of Origin :
China
MOQ :
10,000pcs
Payment Terms :
T/T,Western Union,paypal
Supply Ability :
500KK/month
Delivery Time :
5-15 days
Packaging Details :
2000pcs/reel, Reel+Anti-static bag+carton
Application :
Backlight and Indicator
Color :
RGB
Wavelength :
620-630 / 520-530 / 460-470 nm
Forward Current :
5mA
Forward Voltage :
3.4~5.4v
Size :
3.5*2.8*1.9mm
Warranty :
2 Years
Chip brand :
San'an chip / Epistar chip
Package :
2000pcs/reel
Lifetime :
50,000h
Operating Temperature :
-40℃~85℃
Storage Temperature :
-40℃~100℃
Description


3528 Tri-Color SMD LED RGB PLCC-4 Chip Light Emitting Diode with Black Case for Backlight and Indicator

Features:

  1. 99.99% gold wire bonding
  2. Efficient heat dissipation
  3. Strong anti-static ability
  4. Meet RoHS Green Product
  5. Energy-saving and environmentally friendly



Technical Parameters:

Electrical optical characteristics :(Ta=25°C)

Parameter Symbol Color Min Typ Max Unit Test Condition
Wavelength λd Red
Green
Blue		 620
515
460		 --- 635
525
470		 nm IF=20mA
Luminous intensity Iv Red
Green
Blue
600
1500
450
mcd IF=20mA
Forward voltage VF Red
Green
Blue		 1.8
2.8
2.8		 --- 2.4
3.4
3.4		 V IF=20mA
Viewing angle

--- 120 --- deg IF=20mA
Reverse current IR
--- ---- 5 uA IF=20mA
Operation Temperature －40~+85℃ Size 3.5*2.8*1.9mm
Storage Temperature －40~+100℃ Packing 2000pcs/reel


3528 Tri-Color SMD LED RGB PLCC-4 Chip Light Emitting Diode with Black Case for Backlight and Indicator


Applications:

  1. Commercial lighting
  2. LED backlight and SMD type indicators
  3. LED modules and LED strip lights
  4. Decoration lighting and backlighting in dashboards and switches
  5. Automotive lighting, such as taillights, brake lights, turn lights, and daytime running lights
  6. License plate lamps and in-vehicle lighting
  7. Mobile phones, digital cameras, and flash photoelectric displays
  8. LED grow lights for indoor gardening

Materials:

3528 Tri-Color SMD LED RGB PLCC-4 Chip Light Emitting Diode with Black Case for Backlight and Indicator

Company information:

Dongguan Lanjin Optoelectronics Co., Ltd. established in 2005, a professional manufacturer in producing light emitting diode, LED digital display, SMD LED , through-hole LED and LED PCB assembly service. Covering 2,500 square meters factory plant, with modern purification constant termperature and humidity anti-static production workshop.

Our company has passed ISO9001:2015 international Quality management system certification, and now applying for ISO14001 Environmental management system certification. With 18 years development, we achieved 2 national invention patents, 12 practical new-type patents, 2 software invention patents, all products comply with the EU RoHS standard.

Lanjin has absorbed the advanced manufacturing technology of Japan, Korea and Western Europe. With a high starting point, high quality market positioning, developed high temperature resistance & long life LED. Widely used in communication equipment, swithching power supply, decorative lighting, multi-speaker, DVD and other electronics.

Lanjin always addict to the principle of “ Quality and customer first”, provide customized services according to customer’s demand. LED light the world, Lanjin lights your life!


3528 Tri-Color SMD LED RGB PLCC-4 Chip Light Emitting Diode with Black Case for Backlight and Indicator

Packing and Shipping:


Inner packaging: Anti-static Bag Vacuo Packaging

Outer packaging: Standard export carton packing.

3528 Tri-Color SMD LED RGB PLCC-4 Chip Light Emitting Diode with Black Case for Backlight and Indicator

3528 Tri-Color SMD LED RGB PLCC-4 Chip Light Emitting Diode with Black Case for Backlight and Indicator

FAQ:

Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable .free samples will be available.We can
also make samples according to your requirements.

Q2: What’s the delivery time?

A: It usually takes about 5-7 days to produce an order. But the exact delivery time might be different for different orders or at
different time.

Q3:What's your warranty terms?

A: The warranty for all our Led products is 2 years.

Q4: How does your factory do regarding quality control?

A: Quality is priority.We always believe Quality is our marketing and attach great importance to quality control from the very
beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for
shipment.
