Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Automatic Paper Coating Machine 380V with 200kg/h Extruder
Specifications
Brand Name :
Laiyi
Certification :
CE
Place of Origin :
Changzhou
MOQ :
1 set
type :
paper coating machine
condition :
new
automatic gra :
automatic
driven type :
mechanical
voltage :
380V
lifetime :
more than 10 year
Description
Paper Cup Heat Laminator Machine 380V With High Performance Extruders
1. Double-sided adhesive release papers

Double-sided adhesive release papers and photo papers, etc

2. Double-sided adhesive release papers
Technical parameters
Machine specification 1200mm/1400mm/1700mm
Effective width Max1100mm/1300mm/1600mm
Machine speed 350m/min
Extruder LD-90mm/LD-100mm “Automatic lifting type extruder"
Extruder power 45-55kw
Extruder output Max 200kg/h or 250kg/h
Used resins Coated resins like LDPE/LLDPE/PP/EVA/EAA
Coating thickness 8-45μm
Thickness uniformity ≤±5％
Unwinding diameter Max Φ1200mm
Rewinding diameter Max Φ1200mm
Basic material Paper(35-200g/㎡)
Tension control Full automatic tension roller closed-loop constant tension control of unwinder and rewinder
Control mode Human-machine interface, extrusion thickness is automatically precision calculated by computer, whole machine linkage control
Frequency converter Imported AC digital vector control inverter
Machine Dimension(L*W*H) 21.85*(9.5-12)*4.5m
3. Double-sided adhesive release papers
Product Application

Jiangsu Laiyi designs and manufactures extrusion laminating/coating lines on the strength of a thorough expertise in the co-extrusion of special polymers - customized and modular layout to meet the demand for special products; - chill-roll unit with precise temperature control - rapid cooling system - special winders and unwinders suitable for any final application.

Jiangsu Laiyi extrusion and co-extrusion units at the forefront of technology, boasting a high manufacturing quality with components suitable for processing also corrosive polymers. we has focused on high performance extruders with special screw design for a wide range of materials like LDPE, SURLYN, EVA, EAA, PP, with customized solutions including different layers, sizes and die widths.

4. Double-sided adhesive release papers
Main Features
  • Double Shaft-less paper roll stands suitable for 3-6 inch paper core,automatic lift ,easier operation .
  • Auto splicer device realize paper in 150-300 m/min speed exchange without decrease machine line speed
  • Ultrasonic type EPC system,makes frequent replacement materials operation more simple
  • Hydraulic lamination structure design , can make coating thinner and firm .
  • Trimming device make the finished coated paper rolls even
  • Special cutting knife and rewinder design makes high speed rewinding shafts exchange possible
