Desktop Rubber Two Roll Open Mill For Rubber 0.3kg Mixing Capacity
Desktop Rubber Two Roll Open Mill For Rubber 0.3kg Mixing Capacity
Desktop Rubber Two Roll Open Mill For Rubber 0.3kg Mixing Capacity
Desktop Rubber Two Roll Open Mill For Rubber 0.3kg Mixing Capacity
Desktop Rubber Two Roll Open Mill For Rubber 0.3kg Mixing Capacity
Desktop Rubber Two Roll Open Mill For Rubber 0.3kg Mixing Capacity
Specifications
Brand Name :
Lixian
Model Number :
HZ-7015
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD 2000~6000/ per set
Payment Terms :
L/C, T/T, D/A, D/P, Western Union,
Supply Ability :
500 sets/per month
Delivery Time :
7days
Packaging Details :
Standard export wooden case
Model :
HZ-7015
Working type :
Electric heating type
Roller Diameter :
60mm/2.5inch
Roller face width :
200mm
Mixing capacity :
0.1~0.3kg
Picking device :
SUS304 Stainless steel hopper
Roller temperature :
room temperature~300℃
Heating method :
Water-cooled cooling
temperature controller :
PID control
Temperature accuracy :
±3℃
Roller spacing :
0.1～10mm adjustable
Motor power :
2.5KW
Description

Desktop Rubber Two Roll Open Mill For Rubber 0.3kg Mixing capacity

Open rubber mixing mill HZ-7015A.pdf

Rubber Two Roll Open Mill Equipment Summary

This machine suitable for plastic industry polymer material mixing and processing such as, PVC, color master batch. Making the raw material and compound mixing, and achieve the required color and quality. The machine adopts special heated mold, roll surface temperature uniformity, never take off a layer, sample thickness can be mixed, the machine safety protection device, convenience to use.

Rubber Two Roll Open Mill Technique Feature:

  • The core technology from Taiwan, The main parts adopt the French schneider.
  • Water-cooled, surface temperature by water cycle at room temperature - water temperature, at the same time temperature uniformity
  • Roll adopts the vanadium titanium alloy chilled cast iron,roll hardness(HRC)50-60,surface is hard wear-resisting, durable. Roller lumen finish machining to ensure that the roller body cooling quickly and evenly.
  • The machine adopts manual adjustment mode, Thickness control precision,easy operation,High safety factor .
  • The machine is equipped with an emergency brake, When emergency accidents,four corners have emergency switch, a number of brake system, convenient quick stop machine.

Rubber Two Roll Open Mill Technical Parameters

Model Number
HZ-7015
After-sales Service Provided
Engineers available to service machinery overseas
Type
Open Mixing Mill
Roller Diameter
60mm/2.5inch
Roll surface width
200mm
Mixing capacity
0.1~0.3kg
Roller temperature
room temperature~300℃
Heating method
electric heating
Roller ratio adjusted
1:1.22/1:1.35 1:1.4
Temperature accuracy
±3℃
Power
2.5KW

Desktop Rubber Two Roll Open Mill For Rubber 0.3kg Mixing Capacity

Desktop Rubber Two Roll Open Mill For Rubber 0.3kg Mixing Capacity

Desktop Rubber Two Roll Open Mill For Rubber 0.3kg Mixing Capacity
