Footwear Testing Machine National Standard Shoes Abrasion Testing Machine Load 4.9N Adjustable Abrasive Wheel Speed 100-300r/Min
Footwear Testing Machine National Standard Shoes Abrasion Testing Machine Load 4.9N Adjustable Abrasive Wheel Speed 100-300r/Min
Footwear Testing Machine National Standard Shoes Abrasion Testing Machine Load 4.9N Adjustable Abrasive Wheel Speed 100-300r/Min
Footwear Testing Machine National Standard Shoes Abrasion Testing Machine Load 4.9N Adjustable Abrasive Wheel Speed 100-300r/Min
Footwear Testing Machine National Standard Shoes Abrasion Testing Machine Load 4.9N Adjustable Abrasive Wheel Speed 100-300r/Min
Footwear Testing Machine National Standard Shoes Abrasion Testing Machine Load 4.9N Adjustable Abrasive Wheel Speed 100-300r/Min
Specifications
Brand Name :
Lixian
Model Number :
HZ-3602
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 sets per month
Delivery Time :
7 work days
Packaging Details :
Wooden case
Model :
HZ-3604
Abrasive wheel speed :
100-300r/min adjustable
Load :
4.9N (specific request can adjust below 19.6N)
Balance range :
5000g, accuracy 5g
Fluctuation of speed :
≤±5 rot/min
Timing shutdown range :
1sec to 99 H, adjustable at every second
Testing speed :
1 to 9999 rot/min
Weight :
80kg
Description

Footwear Testing Machine National Standard Shoes Abrasion Testing Machine Load 4.9N Adjustable Abrasive Wheel Speed 100-300r/Min

Shoes Abrasion Testing Machine Equipment summary:
HZ-3604 National standard shoes abrasion tester is mainly doing abrasion test for the rubber soles, TPR soles, PU soles and plastic shoes. Testing wear resistance of finished shoes.
Main function:
The principle is to press the rotating grinding wheel vertically on the sample, perform abrasion test on the sample at a certain load, speed and time, and measure the length of the test wear mark.
Shoes Abrasion Testing Machine Technical parameters:
Model
HZ-3604 National Standard Shoes Abrasion Testing Machine
Abrasive wheel spe
Dia 20±0.1, thick 4±0.1mm, T12 steel wheel with 72 teeth teeth angle 90°±5°,teel width 0.2±0.05mm,teeth tip roughness Ra=3.2um,hardness HRC≥55,coaxial degree 0.03mm
Abrasive wheel speed
100-300r/min adjustable
Load
4.9N (specific request can adjust below 19.6N)
Balance range
5000g, accuracy 5g
Fluctuation of speed
≤±5 rot/min
Timing shutdown range
1sec to 99 H, adjustable at every second
Testing speed
1 to 9999 rot/min
Timer
1 sec to 99 H
specimen
Thickness ≥6mm
size
600×500×700(mm)
Weight
About 80kg
