ASTM E96 WVTR Water Vapor Transmission Rate Test Chamber
ASTM E96 WVTR Water Vapor Transmission Rate Test Chamber
ASTM E96 WVTR Water Vapor Transmission Rate Test Chamber
ASTM E96 WVTR Water Vapor Transmission Rate Test Chamber
Specifications
Brand Name :
Skyline
Model Number :
SL-FL609
Certification :
CE, Rosh, Calibration
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram, In Cash
Supply Ability :
30 unit / month
Delivery Time :
7 working days
Packaging Details :
plywood case
temperature control Accuracy :
18 ~ 50℃±0.5℃
Temperature resolution :
±0.1℃
Adjustable relative humidity :
40 ~ 95%RH; ±2%RH
Air flow :
0.1 ~ 0.8m/s
Speed :
1 ~ 15r/min
The number of cups :
8 ASTM standard for single layer
Machine size :
750×720×1400mm
Weight: :
110kg
Power source :
AC220V 50Hz 3500W
Description

Water Vapor Transmission Rate WVTR Tester

ASTM E96 WVTR Water Vapor Transmission Rate Test Chamber

Application

It is used for Water Vapor Transmission Rate tests of various fabrics, membrane materials and coated fabrics

Test standard

GB/T 12704,ASTM E 96,JIS L 1099,BS 7209

Features

1, touch screen control, Chinese and English menu, man-machine dialogue mode, convenient operation.

2, rotating sample placement frame, 1 ~ 15r/min speed adjustable, the test results than the fixed sample frame uniform.

3, high precision temperature and humidity sensor, control using PID algorithm fluctuation is small, effectively prevent temperature and humidity overshoot.

4, including temperature and humidity calibration function, can be very good to avoid the sensor deviation caused by long-term use.

5, MCU control, color touch screen operation, modular design, temperature and humidity digital setting, intelligent control, real-time display of temperature and humidity and timing time.

6. Input parameters on the touch screen to calculate WVT g/(h.m²), WVP g/(h.MHg.m ²), PV g.cm/(h.MHg.m ²) value.

7, the instrument is equipped with PC software, temperature and humidity curve can be recorded, convenient for a large number of data report calculation and printing, suitable for a variety of standards and measurement methods.

Main parameters

Adjustable temperature control Accuracy 18 ~ 50℃±0.5℃
Temperature resolution ±0.1℃
Adjustable relative humidity 40 ~ 95%RH; ±2%RH
Air flow 0.1 ~ 0.8m/s
Speed 1 ~ 15r/min
The number of cups 8 ASTM standard for single layer
Machine size 750×720×1400mm
Weight: 110kg
Power source AC220V 50Hz 3500W
