ASTM D8184 Ferrous Wear Debris Monintor PQ Index Analyzer
ASTM D8184 Ferrous Wear Debris Monintor PQ Index Analyzer
ASTM D8184 Ferrous Wear Debris Monintor PQ Index Analyzer
ASTM D8184 Ferrous Wear Debris Monintor PQ Index Analyzer
ASTM D8184 Ferrous Wear Debris Monintor PQ Index Analyzer
ASTM D8184 Ferrous Wear Debris Monintor PQ Index Analyzer
ASTM D8184 Ferrous Wear Debris Monintor PQ Index Analyzer
ASTM D8184 Ferrous Wear Debris Monintor PQ Index Analyzer
Specifications
Brand Name :
AI
Model Number :
PQ-3
Certification :
ISO
Place of Origin :
China
MOQ :
1 set ASTM D8184 Ferrous Wear Debris Monintor
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
100 sets per month
Delivery Time :
30 days
Packaging Details :
ASTM D8184 Ferrous Wear Debris Monintor packed in plywood case
Test standard :
ASTM D8184
Power Supply :
AC110~240V, 50/60Hz
Measuring range :
0~15000PQ
Sample volume :
5ml
Display :
5.6-inch color LCD touch screen
Dimension :
402×266×186mm3
Weight :
6KG
Warranty :
1 Year
Description

Introduction:

This Ferrous Wear Debris Monintoris mainly used for rapid quantitative analysis of ferromagnetic wear particles in oil and measuring the PQ index in oil samples.
PQ index is a dimensionless quantitative number with a good linear relationship with the content of ferromagnetic wear particles in the sample and the size of the wear particles. Since the PQ index is more sensitive to large size ferromagnetic abrasive particles, it is often used in combining with elemental analysis to improve the fault detection rate.
Each operation option is displayed in the display through a 5.6 inch touching screen interface. The user can select the applicable test method and name the measurement data through the detailed settings, or quickly test the oil through the default settings. The results will be displayed in real time during the measurement.
The oil samples recommended to put into the oil sample bottle to do measurment. the instrument is equipped with a 4.5ml oil sample bottle and the matching the conversion ring.

Technical specifications:


Measure range 0~15000PQ
Sample volume 5ml
Capture wear particle >5 μm (ferromagnetic wear particles)
Repeatability
Measure stable oil samples (such as 750 standard samples), repeat the measurement 100 times, and 90% of the data is within ±0.5% or ±3PQ
Power Supply AC110~240V, 50/60Hz
Size 402×266×186mm3
Standard package
Ferrous debris monitor+0PQ, 750PQ and 100-120PQ calibration standard+100pcs 5ml oil box+charging adapter+cables
Weight 5KG / Shipping weight:15KG
Reference standard ASTM D8184
