Ultra Pure 50ml Zirconia YSZ Grinding Jar For High Energy Planetary Ball Mills
Ultra Pure 50ml Zirconia YSZ Grinding Jar For High Energy Planetary Ball Mills
Ultra Pure 50ml Zirconia YSZ Grinding Jar For High Energy Planetary Ball Mills
Ultra Pure 50ml Zirconia YSZ Grinding Jar For High Energy Planetary Ball Mills
Ultra Pure 50ml Zirconia YSZ Grinding Jar For High Energy Planetary Ball Mills
Ultra Pure 50ml Zirconia YSZ Grinding Jar For High Energy Planetary Ball Mills
Ultra Pure 50ml Zirconia YSZ Grinding Jar For High Energy Planetary Ball Mills
Ultra Pure 50ml Zirconia YSZ Grinding Jar For High Energy Planetary Ball Mills
Specifications
Brand Name :
Zoli
Model Number :
BMJ-01
Certification :
ISO9001 CE
Place of Origin :
China
MOQ :
1 piece
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
10000 pcs per month
Delivery Time :
within 15 days
Packaging Details :
carton+Pearl wool+wood
Sizes :
50ML-25L
Control System :
Microcomputer
Lid Type :
Screw-on
Noise Level :
Less than 50dB
Max Load Capacity :
0.35kg
Size :
94*88*8
Color :
White
Speed :
0-450rpm
Performance :
High hardness
Application :
Grinding and Mixing
Chamber Volume :
500ml
Warranty :
1 year
Jar Volume :
50ml-500ml
Pot Volume :
1/2/3/5L
Jar Surface Finish :
Polished
Description

Ultra-Pure 50ml Zirconia (YSZ) Grinding Jar for High-Energy Planetary Ball Mills

Our 50ml yttria-stabilized zirconia (3Y-ZrO₂) grinding jar represents the gold standard in contamination-free milling for advanced materials research. Engineered from 99.5% pure zirconia oxide ceramic, this laboratory-grade jar delivers unparalleled performance where metallic contamination must be avoided.

Key Technical Advantages:

  • Material Composition: 95% ZrO₂ + 5% Y₂O₃ stabilization for maximum fracture toughness (8 MPa·m¹/²)

  • Mechanical Properties: Vickers hardness ≥1250 HV (compared to 1500 HV for diamond)

  • Thermal Stability: Withstands repeated cycling from -196°C to 1000°C

  • Surface Finish: Mirror-polished 0.05μm Ra interior minimizes sample adhesion

Precision Engineering Features:
• Interference-fit lid with dual silicone O-rings ensures perfect seal at 800 RPM
• Wear-resistant thread design survives 500+ opening/closing cycles
• Laser-etched capacity markings for precise filling level control
• ISO 13320-compliant spherical geometry for optimal grinding dynamics

Ideal Applications Include:

  • Battery Research: Uniform mixing of NMC/LFP cathode materials

  • Pharmaceuticals: API particle size reduction to <1μm

  • Ceramics: Nano-zirconia powder refinement

  • Metallurgy: Mechanical alloying of Ti-based composites

Quality Assurance:
✓ Each jar undergoes individual ultrasonic inspection for microcracks
✓ Lot-tested with ICP-MS to confirm <0.01ppm metal leaching
✓ Supplied with material certification including XRD phase analysis
