Specifications
Type :
Testing Machine
Accuracy Class :
High Accuracy
Accuracy :
/
Brand Name :
LONROY
Place of Origin :
Guangdong, China
Application :
Auto Testing
customized support :
OEM, ODM, OBM
power :
---
Protection Class :
Ip56
Voltage :
220V Electrical Equipment
warranty :
1 Year
Pressure Sensor Accuracy :
0.04% FS
Working Environment :
0~40 °C, ≤ 65% RH
Power supply :
220 V, 50 Hz
Pressure Range :
0 ~ 10 MPa
MOQ :
1
Description

Gas Densimeter PVT Analyzer Burnett Isothermal-expansion Method Compressibility Tester Temperature-pressure Measuring Ma

Gas Densimeter PVT Analyzer Burnett Isothermal-expansion Method Compressibility Tester Temperature-pressure Measuring Machine

Product Description

The Gas Densimeter/ PVT Analyzer, developed based on the Burnett method, enables automatic temperature control and automatic temperature-pressure measurement. Combined the data analysis software, it can generate a range of gas compressibility factors and gas densities. Further data fitting allows for the derivation of the second virial coefficient (B), third virial coefficient (C), and virial equation of state. This equipment is ideal for developing new petrochemical fluids and assessing their performance under diverse conditions. It also aids in thermodynamics education, helping scientific research understand gas state equations and compressibility factors.

Key Features

1. Multiparameter output: gas density & compressibility factor, plus fitted virial coefficients and virial equation of state

2. High precision: multi-stage expansion eliminates volume and mass calibrations

3. Temperature stability: ±0.02 °C fluctuation, ±0.02 °C accuracy

4. Pressure accuracy: high-grade sensors for reliable data

5. Extensive applicability: -30 °C~100 °C, 0~10 MPa

6. One-touch automation: integrated temperature/pressure control, data collection and processing

Gas Densimeter PVT Analyzer Burnett Isothermal-expansion Method Compressibility Tester Temperature-pressure Measuring Machine

Technical Specification

Measurement Principle

Burnett method

Temperature Range

-30 ~ 100 °C

Temperature Fluctuation

±20 mK

Pressure Range

0 ~ 10 MPa

Pressure Sensor Accuracy

0.04% FS

Data Transmission

USB

Operating System

Windows

Working Environment

0 ~ 40 °C, ≤ 65% RH

Power Supply

220 V, 50 Hz

Gas Densimeter PVT Analyzer Burnett Isothermal-expansion Method Compressibility Tester Temperature-pressure Measuring MaGas Densimeter PVT Analyzer Burnett Isothermal-expansion Method Compressibility Tester Temperature-pressure Measuring MaGas Densimeter PVT Analyzer Burnett Isothermal-expansion Method Compressibility Tester Temperature-pressure Measuring MaGas Densimeter PVT Analyzer Burnett Isothermal-expansion Method Compressibility Tester Temperature-pressure Measuring Ma
