Specifications
Type :
Testing Machine
Accuracy Class :
High Accuracy
Accuracy :
/
Brand Name :
LONROY
Place of Origin :
Guangdong, China
Application :
Auto Testing
customized support :
OEM, ODM, OBM
power :
---
Protection Class :
Ip56
Voltage :
220V Electrical Equipment
warranty :
1 Year
Temperature Control Accuracy :
±3℃
Power Supply :
AC220V±10% 50Hz±5%
Relative Humidity :
10% to 80% Rh
Dimensions :
280*260*380mm
MOQ :
1
Description

Engine Fuel Actual Gum Analyzer Laboratory Fuels Actual Gums Tester Gasoline Actual Gum Measuring Machine

Product Introduction

The actual gum content tester is designed and manufactured in accordance with the requirements stipulated in GB/T 509 "Method for Determination of Actual Gum Content of Engine Fuels". This instrument is suitable for determining the tendency of fuel (gasoline, kerosene, diesel) to form gum when used in engines. It is equipped with a dedicated oil-free silent air compressor and is widely used in departments such as petroleum, chemical industry, power, commodity inspection, quality inspection, universities, and research institutions.

Functional Features

1. The design of the instrument fully complies with the requirements of the GB/T 509 standard.

2. The air supply device is composed of an air compressor, an air filter and a flow meter.

3. Heated by an electric heater with a power of 1000W, for direct heating.

4. The high-temperature oil bath and the control box are separated, with a well-designed layout; the oil bath is made of stainless steel, which is durable and long-lasting.

Engine Fuel Actual Gum Analyzer Laboratory Fuels Actual Gum Tester Gasoline Actual Gum Measuring Machine

Technical Specification

Adaptation Standard

GB/T 509

Temperature Range

Room temperature to 250℃

Temperature Control Accuracy

±3℃

Bathtub Medium

Oil bath (flash point above 310℃)

Oil Bath Capacity

Approximately 5 liters (The oil will expand when heated, so a reserve should be left to ensure it doesn't overflow after heating)

Temperature Control Experiment

Kerosene: 180℃ ± 3℃; Diesel: 250℃ ± 3℃

Input Power

≤1200W

Environmental Temperature

5℃ to 45℃

Relative Humidity

10% to 80% Rh

Power Supply Voltage

220V ± 10% 50Hz

Dimensions of the Shape

Control box: 280×260×380mm; Oil bath: 250×450mm

Engine Fuel Actual Gum Analyzer Laboratory Fuels Actual Gum Tester Gasoline Actual Gum Measuring MachineEngine Fuel Actual Gum Analyzer Laboratory Fuels Actual Gum Tester Gasoline Actual Gum Measuring MachineEngine Fuel Actual Gum Analyzer Laboratory Fuels Actual Gum Tester Gasoline Actual Gum Measuring MachineEngine Fuel Actual Gum Analyzer Laboratory Fuels Actual Gum Tester Gasoline Actual Gum Measuring Machine
