ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
Specifications
Type :
Testing Machine
Accuracy Class :
High Accuracy
Accuracy :
/
Brand Name :
LONROY
Place of Origin :
Guangdong, China
Application :
Auto Testing
customized support :
OEM, ODM, OBM
power :
---
Protection Class :
Ip56
Voltage :
220V Electrical Equipment
warranty :
1 Year
Adaptation Standard :
GB/T 8017, ASTM D323
Power Supply :
220V±10% 50Hz
Power :
≤1100W
Temperature Control Accuracy :
±0.1℃
MOQ :
1
Description

ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine

Product Introduction

The fully automatic saturated vapor pressure tester is designed and manufactured in accordance with the requirements of the Chinese standard GB/T8017 "Method for Determination of Vapor Pressure of Petroleum Products (Reid Method)" and the American Society for Testing and Materials standard ASTM D323. It is suitable for determining the vapor pressure of gasoline, volatile crude oil and other volatile petroleum products, but cannot be used to determine the vapor pressure of liquefied petroleum gas. It is widely used in the fields of petroleum, chemical industry, power, commodity inspection, universities, research institutions, etc.

Functional Features

1. The instrument test process is fully automated.

2. Utilize a 7-inch color TFT LCD screen and touch screen for human-computer interaction

3. The instrument has the function of online temperature adjustment.

4. The execution structure of the instrument is well-designed.

5. The instrument is equipped with a pressure calibration device.

6. The instrument has high testing accuracy.

7. The instrument has the function of online pressure adjustment.

8. The instrument can store 100 test results.

ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine

Technical Specification

Adaptation Standard

GB/T 8017, ASTM D323

Experimental ammunition

Can test 2 samples simultaneously, with the volume ratio of the upper and lower chambers being 4:1

Control Temperature Point

37.8℃

Temperature Control Accuracy

±0.1℃

Power

≤1100W

Mixing Angle

350 degrees

Pressure Range

Gauge pressure: 0 - 200 kPa

Power Supply Voltage

220V±10% 50Hz

ASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test MachineASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test MachineASTM D323 Fully Automatic Saturated Vapor Pressure Tester Reid Method Petroleum Products Vapor Pressure Test Machine
