Specifications
Type :
Testing Machine
Accuracy Class :
High Accuracy
Accuracy :
----
Brand Name :
LONROY
Place of Origin :
Guangdong, China
Application :
Auto Testing, Laboratory Testing, Lab Testing
customized support :
OEM, ODM, OBM
power :
---
Protection Class :
Ip56
Voltage :
220V Electrical Equipment
warranty :
1 Year
Color Representation :
Color space values L*, a*, b* (L, a, b)
Whiteness Representation :
Blue light whiteness Wb
Bran percentage :
≤ 0.02%
Indication Error :
Whiteness ≤ 0.3
MOQ :
1
Description

Bran Speck Analyzer Wheat Flour Processing Precision Analyzer Touch Color Screen Wheat Flour Color Tester Lab Test Machi

Bran Speck Analyzer Wheat Flour Processing Precision Analyzer Touch Color Screen Wheat Flour Color Tester

Product Description

Brief Introduction

The wheat flour processing precision analyzer is suitable for various wheat flour processing enterprises, food and flour processing companies, grain and oil quality inspection stations, grain storage facilities, universities, and research institutions.

Detailed Description

The wheat flour processing precision analyzer (bran speck analyzer) can measure the color of wheat flour, bran speck content, number of bran specks per unit area, maximum bran speck area, and whiteness. It meets the national standards for measuring the processing precision of wheat flour samples. The wheat flour processing precision analyzer conforms to GB/T 5504-2025 "Grain and Oil Inspection - Wheat Flour Processing Precision Inspection" and GB/T 5504-2025 "Grain and Oil Inspection - Determination of Wheat Flour Color and Bran Specks" for the determination of bran specks in wheat flour.

Performance Features

Simple operation, fast speed, results in 1 minute.

Automatically saves multiple photos for comparative analysis.

Fully automatic self-check on startup, stable performance, maintenance-free.

High repeatability and good stability of measurement results.

Directly generates Excel reports for easy data organization and printing.

Can record other sample parameters to enrich sample query information.

Uses a 10.5-inch touch color screen, clear image display, and simple interface.

LBran Speck Analyzer Wheat Flour Processing Precision Analyzer Touch Color Screen Wheat Flour Color Tester

Technical Specification

Measurement Items

Measurement of wheat flour color, bran content, number of bran particles per unit area, maximum bran particle area, and blue light whiteness.

Standards Compliance

Complies with the National Grain Administration's industry standard for wheat flour processing precision sample testing;

Complies with GB/T 5504-2025 "Grain and Oil Inspection - Determination of Wheat Flour Color and Bran Content".

Color Representation

Color space values L*, a*, b* (L, a, b).

Bran Content Representation

Ratio of the bran particle area on the sample surface to the sample surface area (‰).

Whiteness Representation

Blue light whiteness Wb.

Display

10.5-inch high-resolution LCD display (external monitor connectable).

Indication Error

Whiteness ≤ 0.3;

Bran percentage

≤ 0.02%.

Repeatability Accuracy

Difference between two measurements of the same sample < 10% of the average value;

Color difference

E*ab ≤ 0.2

Warm-up Time

10 minutes.

Image Sensor

Resolution > 1 million pixels, continuous scanning, multi-point acquisition and analysis, real-time image display on computer, and image saving.

System Configuration

Integrated computer (Windows 7 OS) and instrument, fully sealed and dustproof, fanless cooling; printer connectable.

Calibration Parts

Equipped with simulated bran plates and a calibrated white board certified by a national metrology institution.

Reporting Function

Data can be queried arbitrarily, measurement records can be queried by date and number; data can be exported and Excel reports can be automatically generated.

Internal Light Source

Simulated D65 illuminant, digitally adjustable light source, fully automatic calibration.

Standard Equipment

One main unit, one set of accessories.
