Specifications
Place of Origin :
China
Brand Name :
Lonroy
MOQ :
1
Voltage :
220V
Protection Class :
IP56
Operating Temperature :
15 - 40°C (60 - 104°F)
Operating Humidity :
Up to 85% without fogging
Dimensions :
65mm x 140mm x 50mm
Weight :
530g
Measurement Angles :
20°, 60°, 85°
Measurement Area 20° :
6mm x 6mm
Measurement Area 60° :
6mm x 12mm
Measurement Area 85° :
4mm x 45.9mm
Power Supply :
Rechargeable lithium battery
Continuous Working Time :
17 hours
Reading Capacity :
Over 10,000 readings
Memory Capacity :
8MB (approx. 2,000 readings)
Charging Duration :
4 hours
Certification :
ISO ASTM CE
Price :
Negotaible
Packaging Details :
Wooden package
Delivery Time :
5-8 work days
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
200
Description
ISO 2813 ASTM D523 Triangular Haze Gloss Meter
The Tri-angle Haze Gloss Tester is a precision measuring instrument that complies with ISO 2813 and ASTM D523 standards, featuring three measurement angles for comprehensive surface gloss analysis.
Product Introduction
This gloss meter measures surface gloss in Gloss Units (GU), traceable to international reference standards from BAM (Germany), NRC (Canada), and NPL (UK). The three measurement angles provide optimal resolution for different surface types:
  • 60° angle: Standard measurement for all surfaces, used as reference for other angles
  • 85° angle: Recommended for low-gloss surfaces (when 60° measurement is <10GU)
  • 20° angle: Ideal for high-gloss surfaces (when 60° measurement is >70GU), particularly sensitive to surface fogging
Product Features
  • Full-color screen with adjustable brightness
  • 6 touch keys for intuitive operation
  • Calibration base with positioning detection
  • One-button measurement of all parameters
  • Fast measurement capability
  • Customizable batch names for measurement results
Technical Specifications
Measurement Parameters Maximum/minimum value, average value, standard deviation, all measurement parameters
Analysis Function Built-in trend analysis, gloss value
Power Supply Rechargeable lithium battery (17 hours continuous operation)
Memory Capacity 8MB (approximately 2,000 readings)
Data Transmission Bluetooth, USB (PC/MAC compatible, no software required)
Dimensions & Weight 65mm * 140mm * 50mm, 530g
Supported Languages Chinese, English, French, German, Spanish, Italian, Japanese, Turkish
Measurement Areas 20°: 6mm * 6mm
60°: 6mm * 12mm
85°: 4mm * 45.9mm
Operating Conditions Temperature: 15-40°C (60-104°F)
Humidity: Up to 85% (non-condensing)
