ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine
ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine
ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine
ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine
ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine
ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine
ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine
ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine
ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine
ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine
Specifications
Type :
Testing Machine
Accuracy :
/
Brand Name :
LONROY
Place of Origin :
Guangdong, China
Application :
Auto Testing
customized support :
OEM, ODM, OBM
power :
4000W
Protection Class :
Ip56
Voltage :
220 V
warranty :
1 Year
Temperature range :
15 - 30℃
Head difference :
0 - 250mm
Power supply :
AC220V 50HZ 4000W
Overall dimensions :
1270*750*1065mm
MOQ :
1
Description

ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine

ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine

Scope of Application

The geotextile vertical permeability performance tester is designed and manufactured in accordance with the latest national standard GB/T15789-2016. It is a constant head tester suitable for testing the vertical permeability performance of various geotextiles and composite geotextiles under constant water head. This machine adopts microcomputer program control, with sensors to collect and measure water volume, and automatically calculates the permeability coefficient.

Compliance Standards

GB/T15789-2016, ASTM D4491-2017 Method A - Constant Head Test

Instrument Features

1. Human-machine interface: Touch screen operation, menu-based operation, simple and clear.

2. Cooling method: Imported compressor.

3. Protection function: Equipped with a water level device, with anti-dry burning function.

4. Control method: Single-chip microcomputer program automatically controls temperature.

5. Clamping method: Vertical.

6. Built-in dissolved oxygen sensor, which can directly display the oxygen concentration of the liquid.

7. The instrument is equipped with a built-in vacuum pump, which can effectively reduce the oxygen concentration of the liquid.

8. Water collection methods can be selected as flow meter or manual water collection.

ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine

Technical Specification

Temperature range

15 - 30℃

Temperature accuracy

0.1℃

Water collection time

30.0 - 999.9 seconds, set arbitrarily

Oscillation frequency

20 - 70 times per minute, stepless speed regulation

Head difference

0 - 250mm

Dissolved oxygen sensor accuracy

0.01mg/kg

Inner diameter of the clamping device

50mm ± 0.2mm

Overall dimensions

1270×750×1065mm

Power supply

AC220V 50HZ 4000W

ASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing MachineASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing MachineASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing MachineASTM D4491 Geotextile Vertical Permeability Performance Tester Geotextiles Permeability Coefficient Lab Testing Machine
