ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine
ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine
ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine
ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine
ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine
ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine
ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine
ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine
ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine
ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine
Specifications
Type :
Testing Machine
Accuracy :
/
Brand Name :
LONROY
Place of Origin :
Guangdong, China
Application :
Auto Testing
customized support :
OEM, ODM, OBM
power :
100W
Protection Class :
Ip56
Voltage :
220 V
warranty :
1 Year
Thermometer range :
(0~50)℃ (accuracy: 0.1℃)
weight :
25kg
Power supply :
AC220V±10%, 50Hz, 100W
Overall dimensions :
(400*500*850)mm
MOQ :
1
Description

ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine

ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine

Scope of Application

It is used for testing the vertical permeability performance of geotextiles and composite materials.

Relevant Standards

GB/T15789, JTG E50, SL/T235, ISO11058, ASTM D4716

ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine

Technical Specification

Maximum water head pressure difference

250mmH2O (2450Pa)

Water level graduation value

1mm

Inner diameter of the clamping device

(50±0.5)mm

Applicable sample thickness

≤20mm

Time controller

(0~99.99) seconds

Graduated cylinder

1000ml (graduation: 10ml)

Water level graduation value

1mm

Thermometer range

(0~50)℃ (accuracy: 0.1℃)

Power supply

AC220V±10%, 50Hz, 100W

Overall dimensions

(400×500×850)mm

Weight

25kg

ISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test MachineISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test MachineISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test MachineISO 11058 ASTM D4716 High Precision Geotextile Hydraulic Conductivity Tester Geotextile Water Permeability Test Machine
