WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
Specifications
Application :
Auto Testing, Laboratory Testing, Lab Testing
customized support :
OEM, ODM, OBM
warranty :
1 Year
Type :
Testing Machine
power :
---
Protection Class :
Ip56
Place of Origin :
Guangdong, China
Price :
$692
Brand Name :
LONROY
Measuring angles :
20°,60°,85°
Accuracy :
/
MOQ :
1
Accuracy Class :
High Accuracy
Voltage :
220 V, Other
Description

WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester

WGG-20/60/85 Multi Angle Glossmeter

Mainly used for measuring the surface gloss of materials in industries such as spraying, plastic, printing, metal, ceramics, building materials, leather, paint, etc.

Standard: DIN 67530,ISO 2813,ASTM D 523,JIS Z8741,BS 3900 Part D5,JJG696

WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester

Technical Parameter

Measuring angles

20°,60°,85°

Measurement spot (mm)

20°:10*10 60°:9*15 85°:5*38

Measurement range

20°:0-2000GU 60°:0-1000GU 85°:0-160GU

Resolving power

0.1GU

Measurement mode

Simple mode, standard and sample measurement mode

Measurement repeatability accuracy

0-100GU:0.2GU 100-1000GU:0.2%GU

Measurement accuracy

Meet the requirements of JJG 696 Level 1 working glossmeter

Measurement time

0.5s

Data storage

Can store 100 standard samples and 10000 samples

Size (mm)

165 * 51 * 77 (length * width * height)

Weight

Approximately 400g

Language

Simplified Chinese, English

Battery level

3000mAh lithium battery

Interface

USB, Bluetooth (optional)

Upper computer software

include

Working temperature

0-40 ℃

Humidity

Less than 85%, no condensation

Parts

5V/2A charger, USB data cable, manual, CD, calibration standard board

WGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss TesterWGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss TesterWGG-20/60/85 ISO 2813 Multi Angle Glossmeter ASTM D523 BS 3900 Tri-angle Digital Gloss Meter DIN 67530 Surface Gloss Tester
