-170C~600C dsc differential scanning calorimeter price

Product Introduction:

The differential scanning calorimeter is touch-screen and can be used for glass transition temperature measurement, phase transition measurement, melting and enthalpy measurement

Value test, product stability, oxidation induction period test, specific heat test, etc. Mainly used in chemical, energy, metallurgy, mineral, polymer materials, metal materials and other industries

-170C~600C dsc differential scanning calorimeter price

Technical parameters:

1. Temperature range: -170~600℃, liquid nitrogen refrigeration

2 temperature resolution: 0.01℃

3 temperature fluctuation: ±0.01℃

4. Temperature repeatability: ±0.1℃

5. Heating rate: 0.1 ~ 80℃/min

6. Constant temperature time: 0~400

7. Temperature control mode: heating, cooling, constant temperature

8.DSC range: 0 ~ ±600mW

9.DSC resolution: 0.001mW

10.DSC sensitivity: 0.001mW

11. Power supply: AC220V/50Hz or customized

12. Cooling equipment: liquid nitrogen cooling

13. Atmosphere control gas: nitrogen, oxygen (automatic instrument switch)

14. Gas flow: 0-300ml /min

15 gas pressure: 0.2mpa

16. Display mode: 24bit color, 7 inch LCD touch screen display

17. Data interface: standard USB interface

18. Parameter standard: equipped with standard material (indium, tin), users can adjust the temperature

19. Upper computer operation software, coordinate range automatically switch, no manual adjustment; Software analysis results can be dragged at will display position

20. The instrument has multiple groups of thermocouples, one group to test the sample temperature, one group to test the internal environment temperature of the instrument, and one group to test the furnace temperature

Technical features:

1. Industrial grade 7 inch touch screen, display rich information.

2. New furnace body structure, can be matched with a variety of refrigeration devices.

3.USB communication interface, strong commonality, reliable communication without interruption, support self-recovery connection function.

4. Automatic switching of two air flow, fast switching speed, short stability time. At the same time, a protective gas input is added.

5. Software is simple and easy to operate.

-170C~600C dsc differential scanning calorimeter price

Configuration list
