Specifications
Type :
Testing Machine
Accuracy :
---
Brand Name :
LONROY
Place of Origin :
Guangdong, China
Application :
Auto Testing
customized support :
OEM, ODM, OBM
power :
---
Protection Class :
IP65
Voltage :
220 V
warranty :
1 Year
Test standard :
ISO1133-2011, ASTM D1238
Test methods :
MFR
Power :
AC220V±10% 50/60HZ
Display resolution :
0.1℃
MOQ :
1
Description

ISO 1133 ASTM D1238 Melt Flow Index MFI Measuring Instrument MFI Tester Melt Flow Index Testing Machine Plastic Test

ISO 1133 ASTM D1238 Melt Flow Index MFI Measuring Instrument MFI Tester Melt Flow Index Testing Machine

Discription:

Melt flow rate testing instrument can be used for ABS, polystyrene, polyethylene, polypropylene, polyamide, fiber resin, acrylate, POM, fluorine plastic, polycarbonate and other plastic materials, the melt flow rate (MFR) or the melt volume flow rate (MVR) to be determined.

Standard:

GB/T3682-2018,ISO1133-2011, ASTM D1238

Product Character:

1.English LCD Touched Screen.

2.Hand automatic cutting material.

3.Double temperature control system, temperature control precision is more accurate, higher heating efficienc

4.Double imported sensors, more accurate temperature gradient from top to bottom, can be used independently, and improve the service life.

5. Cylinder for imports hartz alloying nitriding treatment, opening mould for carbon tungsten steel material, material reality.

6.Insulation barrels of sus304 stainless steel material for the whole, long-term high temperature does not rust.

7.Automatic calculation results, and print.

Test Methods:MFR Methods

Display Mode:English color touch screen display

Melt Flow Index / MFI Measuring Instruments and Test Equipment

Specification

Model

LR-A001-A

Barrel parameters

Inner hole 9.550±0.005mm

Pistons parameters

Piston head: 9.474±0.005mm

Outlet length

8.000±0.025mm

Paramters

Extrusion hole 1=2.095±0.005mm

Temperature parameter

With intelligent temperature control instrument, with four pairs of significant temperature setting control, PID parameters can be automatically set, precision up to ± 0.1 degree centigrade

Temperature range

Room Temperature~450degree centigrade

Temperature fluctuation

±0.2 ℃

Temperature uniformity

±1℃

Temperature display resolution

0.1℃

Display resolution

0.1℃

Maximum comsuption

< 600W

Time display resolution

0.1s

Weight parameters are as follows:

Weight accuracy

±0.5%

Basic configuration

A 0.325kg

B 1.2kg

C 2.16kg

D 3.8kg

E 5kg

F 10kg

G 12.5kg

H 21.6kg

Position detection

Loop distance from up and down

30mm

Control precision

± 0.1mm

Test flow control

Times of cutting the material

0~10 times

Material cutting interval

0~999s(set reference Table 2)

Control flow reaches the set temperature without volatility

Barrel temperature time

15 min.

Material be installed

1 min.

Material sample temperature recovery time

4 min.

When binder set

1min

Output mode

Micro-automatic print output

Cut material methods

The hand automatic cut into one body

Test load

Eight sets of weights

Power

AC220V±10% 50/60HZ
