Specifications
warranty :
1 Year
Place of Origin :
Hunan, China
Weight (KG) :
130
Brand Name :
LONROY
Price :
$1,000
Voltage :
220 V
Machine Type :
Needleless Electrospinning Machine
MOQ :
1
Description
Products Description
Needleless Electrospinning Machine Nanofiber Fabrication Detector Needle-free Electrostatic Spinning Tester Spin Fiber Device

Brief Introduction This electrospinning machine is a device designed to produce polymer nanofibers using electrospinning technology. It primarily consists of a liquid supply system, a spinneret, a high-voltage power supply, and a collection system.
Needleless Electrospinning Machine Nanofiber Fabrication Detector Needle-free Electrostatic Spinning Tester Spin Fiber Device
Detailed Introduction This electrospinning machine is a device designed to produce polymer nanofibers using electrospinning technology. It primarily consists of a liquid supply system, a spinneret, a high-voltage power supply, and a collection system. The liquid supply system utilizes a professional-grade syringe pump for research applications, capable of delivering a continuous and stable flow. The feed rate is adjustable to accommodate the requirements of various spinning solutions. It offers stable pushing force and high-precision control over the liquid feed rate. The standard spinneret is a conventional needle, available in various gauges. It is mounted on an insulated bracket capable of automatic reciprocating motion parallel to the collector, effectively enhancing spinning uniformity. We can also customize coaxial spinnerets to produce core-shell or hollow fibers based on customer requirements, or provide optional multi-spinneret setups to increase production efficiency. The high-voltage power supply offers continuously adjustable output (0–30 kV), ensuring a stable electric field for prolonged electrospinning operations. The standard collection unit is a rotating drum collector with adjustable speed; the drum diameter can be customized. Adjusting the rotation speed allows for effective control over fiber alignment. Custom collection systems—such as XY-axis collectors, mesh collectors, or rotating cage collectors—are also available to meet specific customer needs. Needleless Electrospinning Machine Nanofiber Fabrication Detector Needle-free Electrostatic Spinning Tester Spin Fiber Device
Needleless Electrospinning Machine Nanofiber Fabrication Detector Needle-free Electrostatic Spinning Tester Spin Fiber Device
Needleless Electrospinning Machine Nanofiber Fabrication Detector Needle-free Electrostatic Spinning Tester Spin Fiber Device
Needleless Electrospinning Machine Nanofiber Fabrication Detector Needle-free Electrostatic Spinning Tester Spin Fiber Device
Needleless Electrospinning Machine Nanofiber Fabrication Detector Needle-free Electrostatic Spinning Tester Spin Fiber Device
Specification
Technical Parameters
Category
Item
Specification
Power Supply
AC 220V, 50Hz
Total Power
1.6 kW
High-Voltage Power Supply
Output Voltage
30 kV
High-Voltage Power Supply
Max. Current
1 mA
Temperature & Humidity Control
Heating Method
Carbon fiber infrared heating
Temperature & Humidity Control
Max. Temperature
80°C
Temperature & Humidity Control
Max. Heating Power
1.2 kW
Temperature & Humidity Control
Humidity Control
30%–80% RH
Temperature & Humidity Control
Sensor Accuracy
Temperature: -40–80°C (±0.3°C)Humidity: 0–99.9% RH (±3% RH)
Syringe Pump
Syringe Capacity
50 mL
Syringe Pump
Flow Rate Range
0.005–40 mL/min
Collector
Drum Collector
Ø100 × 250 mm
Dimensions
1000 × 600 × 900 mm
Weight
130 kg
Our Advantages
