DPT-2 Intelligent Transdermal Diffusion Tester with 12 Vertical and 6 Horizontal Diffusion Cells and Precise Temperature Control
DPT-2 Intelligent Transdermal Diffusion Tester with 12 Vertical and 6 Horizontal Diffusion Cells and Precise Temperature Control
DPT-2 Intelligent Transdermal Diffusion Tester with 12 Vertical and 6 Horizontal Diffusion Cells and Precise Temperature Control
DPT-2 Intelligent Transdermal Diffusion Tester with 12 Vertical and 6 Horizontal Diffusion Cells and Precise Temperature Control
DPT-2 Intelligent Transdermal Diffusion Tester with 12 Vertical and 6 Horizontal Diffusion Cells and Precise Temperature Control
DPT-2 Intelligent Transdermal Diffusion Tester with 12 Vertical and 6 Horizontal Diffusion Cells and Precise Temperature Control
DPT-2 Intelligent Transdermal Diffusion Tester with 12 Vertical and 6 Horizontal Diffusion Cells and Precise Temperature Control
DPT-2 Intelligent Transdermal Diffusion Tester with 12 Vertical and 6 Horizontal Diffusion Cells and Precise Temperature Control
Specifications
Brand Name :
SHUOBODA
Model Number :
DPT-2
Certification :
ISO/CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
500 sets/month
Delivery Time :
5~8 working days
Packaging Details :
Plywood packing
Vertical diffusion cell cup :
12 sets
Vertical diffusion cell volume :
6.5±0.1 ml
Horizontal diffusion cell cup :
6 sets
Horizontal diffusion cell volume :
7.5 ± 0.1 ml
Speed setting range :
100-500 rpm/min
Speed resolution :
1 rpm/min
Description

DPT-2 Intelligent Transdermal Diffusion Tester

The transdermal diffusion meter is suitable for drug transdermal diffusion testing of transdermal preparations such as patches, suppositories, and semi-solid preparations. Dry and wet methods can be selected.


Product details

DPT-2 tester is intelligent transdermal diffusion temperature control systems in a novel transdermal drug useful instrument, using a unique heat conduction, ensure that the test vessel for a long time constant work environment, achieve accuracy ≤ ± 0.1 in. (Experimental vessel belongs to wet or dry type) is currently the technology has been declared national patent.

Features

Ÿ can be installed 6 horizontal diffusion cell.

Ÿ can be installed 12 vertical diffusion cell.

Ÿ Alternatively experimental vessel water heating and air thermal

Ÿ LCD display, friendly interface, simple operation

Ÿ Host operating parameters can be preset and stored automatically.

Ÿ Speed ​​control subdivision way power driver stepper motor

Ÿ Built-in PT1000 sensors, controlled by PID

Ÿ Timer function displays the current sampling time points, cumulative total time and sampling points.

Ÿ With self-test and protection function, given a variety of fault signal.

Ÿ External micro-printer functionality.

Ÿ Having a USB storage function, the experimental data retention for viewing.

Specifications

Product model

DPT -2

Vertical diffusion cell cup

12 sets

Vertical diffusion cell volume

6.5±0.1 ml

Horizontal diffusion cell cup

6 sets

Horizontal diffusion cell volume

7.5 ± 0.1 ml

Speed setting range

100-500 rpm/min

Speed resolution

1 rpm/min

Steady speed error

≤±0.2%

Temperature range

Room temperature -45.0 ° C

Temperature resolution

0.1 ° C

Temperature control accuracy

≤±0.3°C

Sampling cycle point

Up to 10 different sampling periods, countdown

Sampling cycle time

Up to 99 hours, 59 minutes, 59 seconds, countdown

power

800W

Working environment

Temperature 5-25 ° C, relative humidity ≤ 80% HR

power supply

AC220V±10%, 50Hz

Product Gallery
DPT-2 Intelligent Transdermal Diffusion Tester with 12 Vertical and 6 Horizontal Diffusion Cells and Precise Temperature Control DPT-2 Intelligent Transdermal Diffusion Tester with 12 Vertical and 6 Horizontal Diffusion Cells and Precise Temperature Control
