RT 1000℃ TGA Thermogravimetric Analyzer Instrument 0 - 1000mg TGA-1000
RT 1000℃ TGA Thermogravimetric Analyzer Instrument 0 - 1000mg TGA-1000
RT 1000℃ TGA Thermogravimetric Analyzer Instrument 0 - 1000mg TGA-1000
RT 1000℃ TGA Thermogravimetric Analyzer Instrument 0 - 1000mg TGA-1000
Specifications
Brand Name :
SHUOBODA
Model Number :
TGA-1000
Certification :
ISO/CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
500 sets/month
Delivery Time :
5~8 workingdays
Packaging Details :
Plywood box
TG range :
0～1000mg
TG accuracy :
±2ug
Heating rate :
0.1-50℃/min
TG resolution :
0.1ug
Temperature accuracy :
±0.1℃
Temperature range :
RT-1000℃
Temperature resolution :
0.01℃
Temperature repeatability :
±0.1℃
Description

TGA-1000 Thermogravimetric Analyzer

Thermogravimetric analysis (TG, TGA) is to observe the change of sample mass with temperature or time during the process of heating, constant temperature or cooling, with the purpose of studying the thermal stability and composition of materials. It is widely used in research and development, process optimization and quality control in various fields such as plastics, rubber, coatings, pharmaceuticals, catalysts, inorganic materials, metal materials and composite materials.

Instrument features

Built-in one-millionth high-precision balance, good stability and repeatability

Use lower dish balance to ensure complete sealing and 100% gas collection

Use Curie point temperature calibration for more accuracy

Built-in digital mass flowmeter, automatic and fast gas switching, fast and stable

Beep reminder at the end of the experiment, automatic data saving

Seven-inch large screen LCD display, graphs and curves are clear at a glance

The software is suitable for computers of various resolutions and can be upgraded online for free

Support user self-programming to achieve full automation of measurement steps

Use temperature compensation to reduce baseline drift

Technical Parameter

Model

TGA-1000

TG range

0～1000mg

TG accuracy

±2ug

Heating rate

0.1-50℃/min

TG resolution

0.1ug

Temperature accuracy

±0.1℃

Temperature range

RT-1000℃

Temperature resolution

0.01℃

Temperature repeatability

±0.1℃

Temperature control method

Full automatic control

Atmosphere control

Gas mass flow meter

Curve scanning

Heating scanning

Standard sample

Ni/Fe

Display method

24-bit color, 7-inch touch screen

Working power supply

AC220V 50Hz/60Hz

Net weight

40KG

Gross weight

60KG

Dimensions (w*d*h)

30*38*70cm

Packing size (w*d*h)

48*40*80cm

Accessories List

NO.

name

quantity

NO.

name

quantity

1

Balance main unit

1 ea

16

Hanging wire

4 pcs

2

Balance controller

1 ea

17

Hanging rod

3 pcs

3

Working program CD

1 ea

18

Standard sample (Ni, Fe)

One each

4

Software dongle

1 ea

19

Calcium oxalate

1g

5

Cooling fan (with power supply)

1 ea

20

100mg ring code

1 pc

6

Power cable

3 ea

21

Calibrator

1 set

7

USB cable

1 ea

22

Instruction manual

1 copy

8

Glass tube fuse (5A)

4 ea

23

Ventilation plastic tube (blue)

3 meters

9

Tweezers

1 ea

24

Ventilation plastic tube (orange)

3 meters

10

Sample spoon

1 ea

25

Phillips screwdriver

1 ea

11

Certificate of conformity

1 copy

26

Flathead screwdriver

1 ea

12

Ventilation joint

4 ea

27

Handkerchief

1 pc

13

Alumina crucible (Φ5×4 mm)

400 ea

28

Soft brush

1 stick

14

Left hanging basket

2 ea

29

Pressure reducing valve connector

2 pcs

15

Right hanging basket

1 ea
