FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH
FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH
FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH
FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH
FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH
FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH
FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH
FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH
FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH
FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH
FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH
FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH
Specifications
Brand Name :
KUNCAN
Model Number :
KC-FC-FC
Place of Origin :
China
MOQ :
500Pieces
Price :
＄1.63/Piece 500-900Pieces
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
1000PCS Per/week
Delivery Time :
16Days
Packaging Details :
PE Bag +Carton
Description

FC to FC Duplex Singlemode Fiber Optic Patch Cable – 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH

Product Description

Technical Specifications

Parameter Description
Product Name FC-FC Duplex Singlemode Fiber Optic Patch Cable
Connector Type FC/UPC to FC/UPC (Duplex)
Fiber Type Singlemode OS2
Fiber Core Size 9/125μm
Cable Diameter 2.0mm / 3.0mm (customizable)
Jacket Material LSZH / PVC / OFNP
Jacket Color Yellow (standard for singlemode)
Insertion Loss ≤ 0.3 dB
Return Loss ≥ 50 dB
Operating Temperature -20°C ~ +70°C
Length Options 1m / 2m / 3m / 5m / 10m / 20m / Custom

Product Introduction

This FC to FC Duplex Singlemode Fiber Optic Patch Cable is designed for high-performance optical signal transmission in long-distance and high-bandwidth networks. Using OS2 9/125μm singlemode fiber, it ensures low insertion loss and stable connection across telecom networks, FTTH installations, and data center backbones.

Duplex configuration supports bi-directional communication with paired fibers in one cable jacket.

Key Features

  • FC/UPC to FC/UPC Connectors – Threaded coupling for secure connection

  • OS2 Singlemode Fiber (9/125μm) – Ideal for long-distance transmission

  • Low Insertion & High Return Loss – Optimized for minimal signal loss

  • Durable Jacket Options – LSZH / PVC / OFNP available

  • Length Customizable – Tailored for various network installations

Application Scenarios

  • Telecom & Metro Networks

  • Fiber-to-the-Home (FTTH) Projects

  • Data Centers / Server Rooms

  • Optical Test Equipment Connections

  • R&D and Lab Fiber Networks

Installation & Safety Notes

  • Ensure connectors are clean before mating to prevent loss

  • Handle with care; do not excessively bend (min bend radius: ~30mm)

  • Store in dry, dust-free environment

  • Match cable type (singlemode) with system specifications

  • Not intended for multimode use (MMF systems)

OEM / ODM Customization Options

Option Description
Connector Type FC/UPC – FC/APC / LC / SC / ST / Hybrid
Fiber Type OS2 (SM) / OM1 / OM2 / OM3 / OM4 (MM)
Jacket Material LSZH / PVC / OFNR / OFNP
Cable Diameter 2.0mm / 3.0mm / Armored
Jacket Color Yellow / Aqua / Orange / Custom
Labeling Serial No. / Length Tag / Logo Sleeving
Packaging PE Bag / Ziplock / Reel Box / Custom Logo Box

FC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTHFC to FC Duplex Singlemode Fiber Optic Patch Cable - 9/125μm OS2 Jumper Cord for Telecom, Data Center, FTTH

FAQ


Frequently Asked Questions (FAQ)

Q1. Are you factory or trade company?
A: We are factory of more than 16 years export experience.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.

Q4. Samples ?
A: 2-5 pieces free samples are available, freight on you. Delivery time usually is 2-3 days. Customized samples will take 5-10 days.

Q5. What is delivery time if we place an order?
A: It depends order quantities. Usually, we can deliver goods within 10-15 working days, for more QTY order, let's confirm when you place official order.

Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.

Q7. How to ship out the cargo?
A: At your request, by sea, by express, all are available.
