High-Speed 110m/min Cable Extrusion Line for PVC TPE TPU XLPO with φ80mm φ90mm φ120mm Specifications
High-Speed 110m/min Cable Extrusion Line for PVC TPE TPU XLPO with φ80mm φ90mm φ120mm Specifications
Specifications
Maximum line speed :
Max 110m/min
Design speed :
80m/min
Keyword :
Cable Extrusion Line
Applicable conductor core wire diameter :
φ1.5mm-φ20mm
screw L/D :
25/26:1
Finished outer diameter :
φ2.5mm-φ25mm
Name :
New Energy Extrusion Production Line
Application :
PVC, TPE, TPU, XLPO
Place of Origin :
China
Brand Name :
Kunbo
MOQ :
1
Packaging Details :
Different packaging methods are adopted according to different modes of transport.
Payment Terms :
L/C,T/T,D/P,D/A
Main machine specifications :
φ80mm, φ90mm, φ120mm;
Description
80mm 90mm 120mm Cable Extrusion Line PVC TPE TPU XLPO 110m/min
Product Overview

We have achieved high acclamation in the industry for offering a top-of-the-line gamut of Cable Extrusion Line in the market. Our extrusion machines are manufactured in different specifications to meet variegated customer needs. Extensively used in stainless steel construction, our Cable Extrusion Line is well recognized for its rugged design, unmatched performance, and low maintenance cost.

Key Features
  • Linear and high yields throughout a wide scope of velocities and weight
  • Robust construction
  • Generation flexibility over a substantial extent of applications
New Energy Extrusion Production Line

EV cables (electric vehicle high-voltage cables) are the core "blood vessels" of electric vehicle energy transmission, responsible for safely and efficiently transmitting high-current electrical energy between high-voltage batteries, drive motors, power electronic equipment (such as inverters, DC-DC converters) and charging interfaces. Their design is fundamentally different from ordinary automotive low-voltage cables and must meet stringent electrical, mechanical and environmental requirements.

Applications

Suitable for extrusion of insulation/sheath of PVC, TPE, TPU, XLPO, and other materials.

Main Process Parameters
  • Extrusion materials: PVC, TPE, TPU, XLPE
  • Main machine specifications: φ80mm, φ90mm, φ120mm
  • Applicable conductor core wire diameter: φ1.5mm-φ20mm
  • Finished outer diameter: φ2.5mm-φ25mm
  • Maximum line speed: Max 110m/min
Model Adaptation Parameters
Screw specification (mm) φ80 φ90 φ120
Maximum screw speed (rpm) 90 90 80
PVC glue output (kg/h) 280 360 500
XLPE glue output (kg/h) 150 180 250
Aspect ratio (L/D) 25/26:1
Drive power (kWAC) 75 90 160
Barrel temperature control area 5 5 6
