80m/min Silicone Rubber Wire Extrusion Line with 100kg/h Extrusion Volume for High-Temperature Cables
80m/min Silicone Rubber Wire Extrusion Line with 100kg/h Extrusion Volume for High-Temperature Cables
80m/min Silicone Rubber Wire Extrusion Line with 100kg/h Extrusion Volume for High-Temperature Cables
80m/min Silicone Rubber Wire Extrusion Line with 100kg/h Extrusion Volume for High-Temperature Cables
80m/min Silicone Rubber Wire Extrusion Line with 100kg/h Extrusion Volume for High-Temperature Cables
80m/min Silicone Rubber Wire Extrusion Line with 100kg/h Extrusion Volume for High-Temperature Cables
80m/min Silicone Rubber Wire Extrusion Line with 100kg/h Extrusion Volume for High-Temperature Cables
80m/min Silicone Rubber Wire Extrusion Line with 100kg/h Extrusion Volume for High-Temperature Cables
Specifications
Inlet specification :
Φ0.6-Φ6mm Φ5-Φ15mm Φ8-Φ26mm
Drive power (kWAC) :
15 18.5 30
Finished outer diameter :
Φ1.3-Φ8mm Φ6-Φ18mm φ9-φ28mm
Insulation material :
Silicone Rubber
Keyword :
Wire Insulation Line
Place of Origin :
China
Brand Name :
Kunbo
MOQ :
1
Packaging Details :
Different packaging methods are adopted according to different modes of transport.
Payment Terms :
L/C,T/T,D/P,D/A
Application :
extrusion of silicone wires and cables
Name :
Silicone Wire Insulation/Sheath Extrusion Line
Conductor specification :
0.35-10mm2 16-120mm2 35-400mm2
Aspect ratio (L/D) :
12:1
Extrusion volume :
100kg/h 280kg/h 400kg/h
Model Number :
EXT65 EXT90 EXT120
Screw speed (rpm) :
50 40 40
Line speed :
Max100m/min
Description
Silicone Wire Insulation/Sheath Extrusion Line 80m/min
Product Overview

High-performance extrusion line designed for silicone wire insulation and sheath production with maximum speeds up to 80m/min, featuring advanced energy-efficient components and intelligent control systems.

Key Components

Motors and Drives: Equipped with high-efficiency gearboxes and motors for low energy consumption. Liquid-cooled gearmotors available for maximum energy efficiency and noise containment. Latest generation Lenze drives ensure precise control of speed and torque.

Electrical and Control Equipment: All electrical equipment produced in-house to ensure maximum quality and service reliability.

Silicone Rubber Cable Characteristics

Silicone rubber cable offers exceptional performance with high temperature resistance (-60℃ to 180℃), cold resistance, acid and alkali resistance, corrosion resistance, and waterproof properties. Features soft structure, convenient radiation, stable electrical performance in extreme environments, outstanding anti-aging performance, and long service life. Widely used in metallurgy, power, petrochemical, electronics, and automotive manufacturing industries.

Application
  • Extrusion production of various high-temperature silicone wires and cables
  • Silicone pipe manufacturing
Features
  • KB 2.0 intelligent control system
  • 19-inch industrial control screen with S7-1200PLC
  • Full set of online detection instruments for automatic process control
  • Automatic wire diameter control, conductor preheating, and head vacuuming
  • Three-stage infrared heating for rapid shaping
  • Uniform post-air heating and automatic vulcanization furnace lifting
  • Prevents pores in extrusion and sulfur deficiency during startup/shutdown
  • Perfect process formula management for product consistency
  • Minimizes dependence on manual operation
Technical Specifications
Extruder Model EXT65 EXT90 EXT120
Conductor Specification 0.35-10mm² 16-120mm² 35-400mm²
Inlet Specification Φ0.6-Φ6mm Φ5-Φ15mm Φ8-Φ26mm
Finished Outer Diameter Φ1.3-Φ8mm Φ6-Φ18mm φ9-φ28mm
Screw Speed (rpm) 50 40 40
Aspect Ratio (L/D) 12:1
Drive Power (kW AC) 15 18.5 30
Insulation Material Silicone Rubber
Extrusion Volume 100kg/h 280kg/h 400kg/h
Line Speed Max 100m/min Max 100m/min Max 100m/min
