Specifications
Brand Name :
HENG HAO
Model Number :
BH-A1D
Certification :
UL CQC TUV ROHS
Place of Origin :
MADE IN CHINA
MOQ :
1000pcs
Price :
USD 0.3 to 0.18 per piece
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10000000pcs per month
Packaging Details :
boxes 43*23*23cm
voltage current :
250V 5A
temperature range :
30 to 150C
life time :
10000 times
size :
15*7.1*3.8mm
use for :
motor, battery pack
case :
metal
Description
Auto Reset Thermal Protector Fuse - Metal Case Thermal Protection Switch
Auto Reset Thermal Protector Fuse Metal Case Thermal Protection Switch
BH-A1D Series Thermostat Principle and Structure
The BH-A1D series provides protection against over-current and over-temperature conditions. These devices are firmly sealed, feature small internal resistance, operate silently, and reset automatically. When current flows through the temperature and current-sensitive bimetal, its status changes in response to over-temperature or over-current conditions, either cutting off or switching on the circuit. BH series protectors are safer than standard protectors, as they eliminate temperature effect lag under sudden high-current conditions.
BH-A1D Series Thermostat Specifications
Electrical Rating DC-12V max 12A; DC-24V max 10A; AC-125V max 8A; AC-250V max 16A
Open Temperature (30~150)±5°C; 5°C a step
Reset Temperature 2/3 of the action temperature with tolerance of ±15°C. Reset temperature can also be provided according to customers' requirement.
Life Times 10000 times
Size L15mm W7.1mm H3.8mm
Lead Wire #20 3135, end half tripping, length is 70mm, or according to customer's require
UL File No E487478
CQC Certificate No CQC16002142881
TUV Certificate No B160592241002
BH-A1D Series Thermal Protector Applications and Instructions
BH series thermal protectors are effective, reliable security protector and alarm devices widely used in various applications including:
  • 1.5 horsepower motors
  • Lighting devices
  • Inverter welding machines
  • Switch power supplies
  • Rechargeable battery packs
  • Fluorescent lamp ballasts
  • Portable power tools
  • Electric appliances and other electrical equipment
These protectors prevent damage from over-current and over-heating caused by abnormal work conditions. Enforced types that can withstand pressure of 3.5MPa are suitable for built-in installation of plastic coated motors.
BH-A1D Thermal Protector Temperature Codes
Code Temperature Code Temperature
30 30℃ 100 100℃
35 35℃ 105 105℃
40 40℃ 110 110℃
45 45℃ 115 115℃
50 50℃ 120 120℃
55 55℃ 125 125℃
60 60℃ 130 130℃
70 70℃ 135 135℃
75 75℃ 140 140℃
80 80℃ 145 145℃
85 85℃ 150 150℃
90 90℃
BH-A1D Thermal Protector Item Number Coding
BH-A1D XXX K
BH Design No.
A Material of case: metal-A; Plastic-B
1 1,15×6.6×3.2 2,15×7.1×3.8
D Resistance value of bimetallic G-high Z-moderate D-low
XXX Open temperature
K Type of Contact: K is Open, No signal is closed
BH-A1D Thermal Protector Technical Drawing
Auto Reset Thermal Protector Fuse Metal Case Thermal Protection Switch
