E5084NL_380 Schneider ULTI 4-Button Programmable Panel Cream White
E5084NL_380 Schneider ULTI 4-Button Programmable Panel Cream White
E5084NL_380 Schneider ULTI 4-Button Programmable Panel Cream White
E5084NL_380 Schneider ULTI 4-Button Programmable Panel Cream White
E5084NL_380 Schneider ULTI 4-Button Programmable Panel Cream White
E5084NL_380 Schneider ULTI 4-Button Programmable Panel Cream White
Specifications
Channel :
12 independent channels
MOQ :
5
Product Series :
Schneider SpaceLogic KNX series
Payment Terms :
T/T
Installation Method :
Flush-mounted
Model Number :
E5084NL_380
Delivery Time :
7 Days
Packaging Details :
Carton
Material :
Flame-retardant plastic
Certification :
CE RoHS
Response Time :
Less than 12 hours
Place of Origin :
EU
Installation Type :
Wall-mounted or embedded
Brand Name :
Schneider
Description
E5084NL_380 Schneider ULTI 4-Button Programmable Panel Cream White

The Schneider Electric E5084NL_380 ULTI 4-Button Programmable Panel is a premium control interface from the ULTI series. This panel features four programmable buttons in an elegant cream white housing, offering sophisticated control for lighting, shading, and scene management in luxury building automation applications.

Technical Specifications
Button Configuration 4 programmable buttons
Button Functions Switching, dimming, blind control, scene recall
Display LED status indicators per button
Protocol KNX TP (Twisted Pair) compatible
Communication Objects Up to 100 objects
Button Labels Customizable with protective overlay
Scene Control 8 programmable scenes
Operating Voltage 24V DC via KNX bus
Power Consumption ≤0.5W from KNX bus
Housing Color Cream White (奶白/380)
Material High-quality plastic with premium finish
Frame Compatible with ULTI series frames
Mounting Flush mount in standard 55mm wall box
Operating Temperature -5°C to +45°C
Storage Temperature -25°C to +70°C
Humidity 5% to 93% RH (non-condensing)
Certifications CE, KNX certified, EN 60669-2-5
Application Scenarios
Luxury residential projects requiring premium control interfaces
High-end hotel suites with elegant design requirements
Executive offices and boardrooms with sophisticated controls
Showroom and exhibition spaces with beautiful control panels
Modern minimalist interior designs requiring seamless integration
Smart home applications where design aesthetics are paramount
