Specifications
Brand Name :
Kuoman
Model Number :
KM500-600W Solar Panel
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, L/C
Price :
USD1-100/pcs
Packaging Details :
standard international carton packing
Delivery Time :
general two weeks, more quantity based on exact quantity
Supply Ability :
10000pcs/month
Cell Size :
182x93mm
Module Dimensions :
1722x1134x30mm
Module Weight :
20.5kg
Maximum Power :
415W
Open-circuit Voltage :
37.92V
Short-circuit Current :
13.99A
Description
Kuoman Common Solar Panel N Type Black Solar Panel 415W 210mmx210mm
Solar Panels Black Solar Panel N Type 415 Watts
N Type Black Solar Panel 415W with 22% Efficiency and Anodized Aluminum Frame N Type Black Solar Panel 415W with 22% Efficiency and Anodized Aluminum Frame
Structural Parameters
Cells 108pcs 182x93mm Monocrystalline solar cells
Module Dimension 1722x1134x30mm (LxWxH)
Module Weight 20.5kg
Frame Anodized aluminum profile
Junction Box Rated current: 25A, IP68, TUV
Cable Length Negative 400mm / Positive 300mm
Connector Compatible with MC4
STC Performance Specifications
Parameter 410W 415W 420W 425W 430W
Maximum Power (Pmax) 410W 415W 420W 425W 430W
Maximum Power Voltage (Vmp) 31.13V 31.32V 31.51V 31.70V 31.88V
Maximum Power Current (Imp) 13.17A 13.25A 13.33A 13.41A 13.49A
Open-circuit Voltage (Voc) 37.73V 37.92V 38.11V 38.30V 38.49V
Short-circuit Current (Isc) 13.91A 13.99A 13.99A 14.15A 14.23A
Module Efficiency STC (%) 21.00 21.25 21.51 21.76 22.02
STC: Irradiance 1000W/m², cell temperature 25℃, AM1.5G
Operating Conditions
Max System Voltage 1000V/1500V DC
Temperature Range -40°C ~ +85°C
Series Fuse Rating 25A
NOTC 45±2℃
Temperature Coefficient of Isc (α-Isc) +0.033%/℃
Temperature Coefficient of Voc (β-Voc) -0.29%/℃
Temperature Coefficient of Pmax (Y-Pmp) -0.39%/℃
N Type Black Solar Panel 415W with 22% Efficiency and Anodized Aluminum Frame N Type Black Solar Panel 415W with 22% Efficiency and Anodized Aluminum Frame
