Specifications
Brand Name :
KUOMAN
Model Number :
KMRX200W
Place of Origin :
China
MOQ :
1set
Supply Ability :
10000pcs/month
Price :
USD1-100/pcs
Packaging Details :
standard international carton packing
Delivery Time :
general two weeks, more quantity based on exact quantity
Name :
Flexible Solar Panel
Panel Dimensions :
115*98.5CM
Work time (h) :
24 Hours
Material :
Poly Silicon
Color :
Black
Max. power :
200W
Solar Cell :
Monocrystalline
Peak Voltage :
18V
Installation :
Easy peel-and-stick adhesive backing
Output Tolerance :
± 3%
Logo Print :
customization
Max System Voltage :
1000/600 V
Maximum Power :
100W
Accessories :
10A charge controller, 10ft cable with alligator clips
Current At Pmax :
8.34A(IMP)
Connector :
Compatible Connector
Maximum Power Voltage :
18V
Description

Flexible Solar Panel 50W Adventures and Mountain Climbing Panel

Product Overview

Redefining off-grid mobility, our ETFE Flexible Solar Panel Series delivers high-efficiency power (100W–500W) in an ultra-slim, bendable form factor. Engineered for life on the move, these panels are the preferred energy solution for RV travelers, marine vessels, outdoor gear manufacturers, and furniture-integrated solar applications across the Americas and Africa. With industry-leading 24.2% cell efficiency and a durable 7/9-layer composite construction, they convert sunlight into usable power even in tight spaces and curved surfaces where rigid panels cannot go.

Black Flexible Solar Panel 50W Adventures and Mountain Climbing Panel

Technical Specifications Table

Parameter Value
Model KM-RX30W
Panel Type Semi-Flexible PERC Monocrystalline
Cell Technology Shingled (Imbrication), No Busbars
Peak Power (Pmax) 31.5W (±3%)
Module Efficiency 23.0%
Voltage at Pmax (Vmp) 18.0V
Current at Pmax (Imp) 1.47A
Open-Circuit Voltage (Voc) 21.38V
Short-Circuit Current (Isc) 1.62A
Dimensions (L×W×H) 502 × 345 × 2.0 mm
Weight 0.65 kg
Surface Material Matte ETFE (Anti-Reflective)
Backsheet Options White / Black Carbon Fiber Composite
Junction Box IP65, Potting Encapsulated
Cable & Connector 18AWG, MC4 or DC5521 Selectable
Operating Temperature -40°C to +85°C
Max System Voltage 60V DC

Packaging & Logistics

Configuration Details
Individual Packaging Protective foam sleeve + poly bag
Master Carton Qty 20 panels
Master Carton Dimensions 63 × 63 × 58 cm
Master Carton Weight 16.0 kg
MOQ (Stock Color) 100 units
MOQ (Private Label) 500 units

Black Flexible Solar Panel 50W Adventures and Mountain Climbing Panel

Black Flexible Solar Panel 50W Adventures and Mountain Climbing Panel

Why OEM Brands, Outdoor Retailers & Distributors Choose Us

For product developers integrating solar into backpacks, marine battery tenders, and off-grid accessories, the KM-RX30W delivers measurable differentiation:

  • True Merchandisable Efficiency: 23% real-world efficiency with shingled cells creates tangible marketing claims. No busbar shadows = better aesthetics and verifiable performance gains competitors cannot replicate with conventional string-ribbon designs.

  • Two Inventory SKUs, Unlimited Applications: White backsheet for hot-climate regions and sailboat dashboards; stealth black for premium hiking gear and tactical equipment. Same core panel, distinct visual identities—reduced stocking complexity for multinational distributors.

  • Certified Component-Level Safety: Full CE, ROHS, FCC compliance with optional UL recognition. Fire-retardant ETFE meets RVIA standards for recreational vehicle integration. OEM partners avoid costly recertification cycles.

  • Private Label Acceleration Program: Your logo, your packaging, your connector preference. We provide pre-certified reference designs, CAD files, and co-branded carton programs starting from 500-unit commitments. No engineering fees for standard color/connector combinations.
