Specifications
Brand Name :
Kuoman
Model Number :
KM410W-430W Solar Panel
Place of Origin :
China
MOQ :
10
Price :
USD1-100/pcs
Payment Terms :
L/C, L/C
Supply Ability :
10000pcs/month
Packaging Details :
standard international carton packing
Delivery Time :
general two weeks, more quantity based on exact quantity
Cell Type :
Monocrystalline
Module Dimension :
1722x1134x30mm
Module Weight :
20.5kg
Max Power Output :
410W-430W
Operating Temperature :
-40°C to +85°C
Max System Voltage :
1000V/1500V DC
Description
N Type Monocrystalline Solar Panel 410W-430W Black Customized Power System
N Type Monocrystalline 410W-430W Black Customized Power System
  • N-Type monocrystalline cells with enhanced durability and efficiency
  • Anodized aluminum frame and IP68-rated junction box for weather resistance
  • Wide operating temperature range (-40°C to +85°C) for extreme climates
  • Compatible with MC4 connectors and 1000V/1500V DC systems for scalable installations
  • Customizable power output (410W-430W) to meet specific project requirements
N Type Monocrystalline Solar Panel 410W-430W with IP68 Junction Box for Customized Power Systems N Type Monocrystalline Solar Panel 410W-430W with IP68 Junction Box for Customized Power Systems
Structural Parameters
Cells 108pcs 182x93mm Monocrystalline solar cells
Module Dimension 1722x1134x30mm (LxWxH)
Module Weight 20.5kg
Frame Anodized aluminum profile
Junction Box Rated current: 25A, IP68, TUV
Cable Length Negative 400mm / Positive 300mm
Connector Compatible with MC4
STC (Standard Test Conditions)
Parameter 410W 415W 420W 425W 430W
Maximum Power (Pmax) 410W 415W 420W 425W 430W
Maximum Power Voltage (Vmp) 31.13V 31.32V 31.51V 31.70V 31.88V
Maximum Power Current (Imp) 13.17A 13.25A 13.33A 13.41A 13.49A
Open-circuit Voltage (Voc) 37.73V 37.92V 38.11V 38.30V 38.49V
Short-circuit Current (Isc) 13.91A 13.99A 13.99A 14.15A 14.23A
Module Efficiency STC (%) 21.00 21.25 21.51 21.76 22.02

STC: Irradiance 1000W/m², cell temperature 25℃, AM1.5G

Operating Conditions
Max System Voltage 1000V/1500V DC
Temperature Range -40°C to +85°C
Series Fuse Rating 25A
NOTC 45±2℃
Temperature Coefficient of Isc (α-Isc) +0.033%/℃
Temperature Coefficient of Voc (β-Voc) -0.29%/℃
Temperature Coefficient of Pmax (Y-Pmp) -0.39%/℃
N Type Monocrystalline Solar Panel 410W-430W with IP68 Junction Box for Customized Power Systems N Type Monocrystalline Solar Panel 410W-430W with IP68 Junction Box for Customized Power Systems
Key Performance Insights
  • Wide Operating Range: The system can function in extreme temperatures from -40°C to +85°C, making it versatile for various environments
  • High Voltage Compatibility: Supports 1000V/1500V DC, ideal for large-scale solar installations where higher voltages improve efficiency and reduce energy losses
  • Temperature Impact on Performance: The temperature coefficients provide critical insights into system performance under different thermal conditions:
    • Power Output (Pmax): Decreases by 0.39% for every 1°C increase in temperature
    • Voltage (Voc): Decreases by 0.29% for every 1°C increase in temperature
    • Current (Isc): Increases slightly by 0.033% for every 1°C increase in temperature
Frequently Asked Questions
What applications is this solar panel suitable for?
It is designed for residential, commercial, travel, and automotive power systems, including grid-tied and off-grid installations.
How does temperature affect performance?
Power output decreases by 0.39% per 1°C rise, while voltage drops by 0.29%. Current increases slightly (0.033% per 1°C).
Is this panel compatible with existing solar systems?
Yes, it uses standard MC4 connectors and supports 1000V/1500V DC, making it integrable with most inverters and mounting systems.
What certifications does the product have?
The junction box is TUV and IP68-rated, ensuring safety and durability in harsh conditions.
Can the panel withstand extreme weather?
Yes, its anodized aluminum frame and wide temperature range (-40°C to +85°C) allow operation in diverse climates.
What is the warranty and lifespan?
Typical product warranties cover 10-12 years, with a performance warranty of 25+ years for power output.
