HAKRC F405 V2 mini flight tower with F4520 flight controller 35A/40A/60A 32-bit ESC for FPV Racing drone

Product Description:

The PCB adopts high-end 6-layer 1oZ thick copper sheet, with strong anti-interference ability. Adopting industrial grade LDO, resistant to high temperatures. Equipped with DJI sky end straight socket, easy to install and solder free. Reserve an external LED light strip with a 10V power supply, and customize the remote control channel for light strip switch control. The image transmission power supply can be freely turned on or off by setting a switch channel at the ground station, facilitating ground reference adjustment. Adopting high-quality Murata capacitors from Japan, with strong filtering performance. Eight motor control signal outputs. RX2 connected to SBUS

• HAKRC 4520V2 FC

  1. The PCB adopts high-end 6-layer 1oZ thick copper sheet, with strong anti-interference ability.

  2. Adopting industrial grade LDO, resistant to high temperature.

  3. Equipped with DJI sky end straight socket, easy to install and solder free.

  4. Reserve an external LED light strip with a 10V power supply, and customize the remote control channel for light strip switch control.

  5. The image transmission power supply can be freely turned on or off by setting a switch channel at the ground station, facilitating ground parameter adjustment.

  6. Adopting high-quality Murata capacitors from Japan, with strong filtering performance.

  7. Eight motor control signal outputs.

  8. RX2 connected to SBUS

• FC Specifications:

  Size: 29 * 29mm (20mm-20mm mounting hole)

  Packaging size: 64 * 64 * 35mm

  Input voltage: 2S-6S Lipo

  Net weight of product: 6g

  Packaging weight: 37g

Flight control parameters:

CPU: STM32F722RET6

IMU: ICM42688 dual gyroscope

OSD: AT7456E

Barometer: integrated

Black box: 16M

BEC: 5V/2A

BEC: 10V/2A

LED: Supports external adjustable LED

Sensor: built-in current sensor

Firmware version: HAKRCF722V2

Receiver: Frsky/Futaba/Flysky/TBS Crossfire/DSMX: DSM2 receiver

Packing list:

1x F4520V2 flight controller

4x M2 shock absorber

1x 8 cables

1x DJI FPV cable

1x Dajiang O3 aviation crew three in one cable

1x instruction manual

Detailed pictures:

FAQ:

What is the brand name of this FPV Drone Accessory?

The brand name of this FPV Drone Accessory is Klesman.

What is the model number of this FPV Drone Accessory?

The model number of this FPV Drone Accessory is Model Number.

Where is this FPV Drone Accessory made?

This FPV Drone Accessory is made in China.

Is this FPV Drone Accessory CE certified?

Yes, this FPV Drone Accessory is CE certified.

What is the minimum order quantity for this FPV Drone Accessory?

The minimum order quantity for this FPV Drone Accessory is 20 pieces.

How much does this FPV Drone Accessory cost?

This FPV Drone Accessory costs 32 USD.

What are the packaging details of this FPV Drone Accessory?

The packaging details of this FPV Drone Accessory are 15cm*15cm*8cm.

What is the delivery time for this FPV Drone Accessory?

The delivery time for this FPV Drone Accessory is 5-8 days.

What are the payment terms for this FPV Drone Accessory?

The payment terms for this FPV Drone Accessory are T/T.

What is the supply ability of this FPV Drone Accessory?

The supply ability of this FPV Drone Accessory is 100 pieces per hour.
