LX-type Electric Single Girder Suspension Crane 6.3ton Span 18.5m Material Handling
LX-type Electric Single Girder Suspension Crane 6.3ton Span 18.5m Material Handling
Specifications
Brand Name :
kiwicrane
Model Number :
LX
Certification :
ISO、CE
Place of Origin :
China
MOQ :
one set
Price :
USD3000~10000 one set
Payment Terms :
MoneyGram, Western Union, T/T, D/P, D/A
Supply Ability :
1000 Sets One Year
Delivery Time :
20 Working Days
Packaging Details :
PALLET
Safety Features :
Overload Protection, Emergency Stop Button, Limit Switch
Span :
18.5M
Lifting Height :
6-18M
Operating Environment :
Indoor
Control Method :
Pendant Controller/Radio Remote Control
Warranty :
1 Year
Working Temperature :
-20℃ To 40℃
Crane Speed :
20/5 Meters Per Minute
Capacity :
6.3T
Type :
Suspension Crane
Hoisting Speed :
5/0.8 M/min
Power Supply :
3-phase AC, 220-460V, 50/60Hz
Application: :
Material Handling
Description

LX-type electric single girder suspension crane 6.3ton span 18.5m Material Handling

1. Lightweight structure, space saving:
Suspended installation: The track is directly installed on the lower flange of the roof truss of the factory or a special support structure (such as H-beam). The main beam of the crane is suspended under the track through the walking wheels on the end beam.
No need for columns: Unlike traditional bridge cranes that require ground column support, suspended cranes do not occupy ground space, and the area below can be used completely freely, which is convenient for material transportation and equipment layout.
Make full use of the height of the factory: Since the track is installed at a high place, the crane itself has a compact structure, which can maximize the use of the headroom height of the factory and provide a larger effective lifting space.
LX-type Electric Single Girder Suspension Crane 6.3ton Span 18.5m Material Handling
2. Moderate lifting capacity: The lifting capacity of 6.3 tons belongs to the small and medium tonnage range, which is very suitable for common material handling, equipment maintenance, assembly line feeding and other tasks, covering most light and medium-sized industrial application scenarios.
3. Flexible operation:
Trolley operation: The main beam of the crane runs along the length of the factory (track direction).
Trolley operation: The electric hoist (with hook) runs along the length of the main beam.
Lifting: The electric hoist completes the vertical lifting of heavy objects.
The combination of these three directions of movement can achieve precise positioning of any point in the coverage area.
4. Electric drive, easy operation:
The operation of the trolley, the trolley, and the lifting action are usually driven by independent motors.
Flexible operation: Common ones include ground-following flashlight operation (the button box moves with the hoist), wireless remote control operation (the operator can freely control in a safe position), and cab operation (less used for this tonnage suspension machine).
Simple control, smooth movement, and relatively accurate positioning.
LX-type Electric Single Girder Suspension Crane 6.3ton Span 18.5m Material Handling
ParameterSpecification
TypeElectric Suspension Crane
Capacity (Lifting Load)5 ton (5000 kg)
Span9m
Lifting HeightCustomizable (e.g., 6m, 9m, etc.)
Lifting Speed5/0.8m/min (standard)
Trolley Travel Speed20/5 m/min (VFD)
Bridge Travel Speed20/5 m/min (VFD)
Power Supply3-phase, 380V/50Hz (or as required)
Control MethodPendant control / Radio
Duty ClassFEM 1Am / ISO M3 (Light-Medium Duty)
Protection LevelIP55 (Dust & Waterproof)
Safety FeaturesOverload limiter switches, emergency stop
