Product Basic Performance :

Core Parameters

1. Dimensions: 600*760*1950mm (length*width*height), featuring a vertical double-door design suitable for kitchen workflow layout.

2. Cooling System: Frost-free air-cooling technology with all-copper evaporator and condenser (increased corrosion resistance by 40%).

3. Power Core: Wanbao compressor with a running power of 310W, supporting ultra-low temperature storage from 5°C to -18°C.

4. Volume Efficiency: 0.5 cubic meters effective volume with 6 detachable shelves, each capable of holding ≥25kg.

5. Temperature Control Precision: ±1.8°C intelligent constant temperature with quick freeze mode.

Engineering Innovations

- The evaporator uses a 3D honeycomb fin structure, increasing heat exchange efficiency by 27%.

- The door is equipped with double-layer rubber seals, achieving A-grade air tightness according to national standards.

Product Features:

Advantages of Air-Cooling System

1. Smart Defrosting: Automatically defrosts every 12 hours (operating time ≤8 minutes) to ensure continuous cooling efficiency.

2. Energy Consumption Control: Equipped with PWM frequency conversion technology, daily power consumption ≤14.8 kWh under 25°C ambient temperature conditions.

3. Low-Temperature Compensation: Supports normal startup at -10°C ambient temperature, suitable for cold storage transition areas.

Structural Design Highlights

1. Cabinet Material: Reinforced stainless steel inner liner with galvanized steel outer shell.

2. Safety Protection: IPX4 water resistance rating and high-temperature alarm dual protection.

3. Maintenance Convenience: Front-mounted defrost water collection tray, supports tool-free disassembly and cleaning.

Applicable Scenarios

Catering Processing

- Central Kitchens: Bulk storage of meal kits and pre-prepared dishes (supports GN1/1 standard trays).

- Bakery Workshops: Rapid freezing and shaping of dough (achieves surface hardening within 15 minutes using quick freeze mode).

Cold Chain Circulation

- Fresh Supermarkets: Temporary storage of frozen goods (up to 150 door openings per day).

- Pharmaceutical Warehousing: Storage of laboratory samples (temperature recording module required).

FQ&A Expansion:

1. Q: How is daily power consumption calculated?

A: For the 310W model, the theoretical value is 14.8 kWh per day (when environmental temperature ≤ 32°C). In actual use, it is recommended to reserve a 20% margin.

2. Q: How long should the unit be left undisturbed after transportation?

A: It is suggested that the tilt angle does not exceed 35°, and the unit should be left undisturbed for at least 6 hours before powering on.

3. Q: How can shelf spacing be adjusted?

A: The design uses snap-fit, with each adjustment increasing height by 8 cm, and supports asymmetric layout.

4. Q: What are the usage limitations in extreme low-temperature environments?

A: The operating temperature range is -10°C to 43°C. Below -10°C, low-temperature compensation mode must be activated.

5. Q: What is the replacement cycle for door seals?

A: It is recommended to replace them every 3 years. Special pressing tools are required for self-replacement.

Note: The product complies with EU CE certification. It is recommended to use an environmental temperature monitoring system to extend equipment lifespan.

Technical Parameters:

Feature Picture:
