Product Basic Performance

Core Parameters

1. Dimensions: 600*760*1950mm (length, width, height).

2. Cooling System: Air-cooled circulation technology with all-copper evaporator and condenser.

3. Compressor: Wan Bao high-efficiency energy-saving compressor, 260W for refrigeration model, 310W for freezing model.

4. Volume Efficiency: 0.5m³ capacity with adjustable shelves.

5. Temperature Range:

- Refrigeration model: 2℃ to 8℃.

- Freezing model: -18℃ to 5℃.

6. Certification Standards: CE certification + ROHS environmental certification.

Technical Highlights

- Glass door models feature 3-layer Low-E tempered glass (transparency ≥ 85%, thermal coefficient ≤ 0.65W/㎡·K).

- High-density polyurethane insulation layer (improves insulation performance by 30%).

Product Features

Advantages of Air-Cooled System

1. Frost-free Technology: Intelligent defrosting cycle (runs for 3 minutes every 8 hours).

2. Temperature Uniformity: ±1.5℃ temperature control, superior to traditional direct-cooling models.

3. Humidity Management: Constant humidity at 85%RH (exclusive fruit and vegetable preservation mode for refrigeration model).

Engineering Structural Design

1. Stainless steel interior with anti-corrosion coating process.

2. Door Seals: Made from EPDM rubber (temperature range -40℃ to +120℃).

3. Safety Protection: IPX4 water resistance rating .

Application Scope

Catering Industry

- Tea Restaurants: Glass door models suitable for displaying beverages/desserts (operating condition with 200 door openings per day).

- Bakeries: Freezing model suitable for dough storage (supports GN1/1 standard baking trays).

FQ&A Expansion:

1. Q: Average daily power consumption?

A: Refrigeration model approximately 12 kWh/day (260W), freezing model approximately 15 kWh/day (310W).

2. Q: Limit on door opening and closing frequency?

A: Hinge design supports ≥500,000 cycles (equivalent to 300 cycles per day).

3. Q: Anti-fog measures for glass doors?

A: Built-in electric heating film (15W power, automatically starts and stops when the ambient temperature is above 25℃).

4. Q: Compressor warranty policy?

A: Whole machine warranty of 1 year, compressor extended warranty up to 3 years.

5. Q: Can internal shelves be customized?

A: Supports GN1/1 (530x325mm) standard baking tray racks/hanging hooks as optional accessories.

6. Q: Extreme environment operating capability?

A: Operating environmental temperature range -10℃ to +43℃ (requires 10cm clearance for heat dissipation).

7. Q: Cleaning and disinfection recommendations?

A: Monthly food-grade hydrogen peroxide spray disinfection (strong acids and alkalis prohibited).

Technical Parameters:

Feature Picture:
