Specifications
Brand Name :
Kimpok
Model Number :
KP-12VTX8W
Certification :
CE Cerfication
Place of Origin :
China
MOQ :
1 piece
Price :
Negotiation
Payment Terms :
T/T,Western Union,paypal
Supply Ability :
5000 pieces/month
Delivery Time :
3-7 work days
Packaging Details :
International Standard Packing
Type :
Wireless Video Transmitter
System :
FPV System
Frequency :
1.2G(1080M-1360M)
Transmit power :
8W
Description

1.2G VTX 1.2Ghz 8W FPV Video Transmitter Receiver Ultra Long Range Video Link Image Transmission Drone VTX 1080M-1360M VTX


Transmitter Parameter:


Product name

Analog video transmitter

Voltage

DC 10V~36V

Current

1.6A

Modulation

FM

Frequency

1200Mhz

Channels

8 channels

Frequency band

1080Mhz, 1120Mhz, 1160Mhz, 1200Mhz, 1240Mhz, 1280Mhz, 1320Mhz, 1360Mhz

Transmit Power

8 watt

Video Output

1 Vp-p(FM)

Temperature

-10℃ ~ +50℃

Antenna port

SMA female

Transmitter Weight

104g

Dimensions

98*55*18mm (without antenna)


Receiver Parameter:


Frequency

1.2Ghz

Channel

12 channels

Frequency band

1080Mhz, 1120Mhz, 1160Mhz, 1200Mhz, 1240Mhz, 1280Mhz, 1320Mh, 1360Mhz

Power input

DC 12V

Receiving sensitivity

-85dBm

Weight

114g

Dimension

116*80*21mm


1.2G VTX 1.2Ghz 8W FPV Video Transmitter Receiver Ultra Long Range Video Link Image Transmission Drone VTX

1.2G VTX 1.2Ghz 8W FPV Video Transmitter Receiver Ultra Long Range Video Link Image Transmission Drone VTX

1.2G VTX 1.2Ghz 8W FPV Video Transmitter Receiver Ultra Long Range Video Link Image Transmission Drone VTX

1.2G VTX 1.2Ghz 8W FPV Video Transmitter Receiver Ultra Long Range Video Link Image Transmission Drone VTX

1.2G VTX 1.2Ghz 8W FPV Video Transmitter Receiver Ultra Long Range Video Link Image Transmission Drone VTX

1.2G VTX 1.2Ghz 8W FPV Video Transmitter Receiver Ultra Long Range Video Link Image Transmission Drone VTX
