1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission
1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission
1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission
1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission
1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission
1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission
1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission
1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission
1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission
1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission
1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission
1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission
Specifications
Brand Name :
Kimpok
Model Number :
KP-T5816
Certification :
CE Cerfication
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C,Western Union,Paypal
Supply Ability :
5,000 pieces per month
Delivery Time :
3-7 Work Days
Packaging Details :
International standard packing
Channel :
48CH
Frequency Range :
5362MHz- 5945MHz
Power Supply :
7-36V DC 2-8S
Weight :
15.8g
Description

1.6W 5.8GHz 48CH FPV Video Transmitter 15.8g Lightweight VTX for FPV Drones Stable Long-Range Transmission

​

Description:

  • 1.6W 5.8G VTX 48CH FPV Video Transmitter brings excellent performance at an affordable price.1.6W power balances energy consumption and transmission distance to realize stable picture transmission.


  • The 5.8GHz frequency band combined with 48 channels can easily cope with multi-camera competition scenarios, fast channel switching, effectively avoiding signal conflicts, and guaranteeing a clear and smooth picture.


  • It also adopts 15.8g lightweight design, perfectly adapted to small traversing aircraft and aerial photography equipment, reducing the load on the aircraft and enhancing the flexibility of flight. Its compact body design makes it easy to install and carry.

​

Channel

48 CH

Frequency Range

5362MHz- 5945MHz

Power Supply

DC 7-36V 2-8S

Weight

15.8g

Input Voltage:7-36V DC;

2-8S Output Voltage: 5V 1A 12V

Input Current: 180mA@Pitmode, 200mA@25mW, 330mA@400mW, 410mA@800mW, 620mA@1600mW

Channels: 48CH (A.B.E.F.R.L;5362MHz-5945MHz)

Power: PIT/25/400/800/1600 mW

Antenna connector: MMCX

Smart Audio: IRC-tramp

Shell Material: Aluminum

Dimensions:37.7*36.1*9.5 mm;30.5*30.5mm(hole)

Weight:15.8g

​
