4W 300Mhz Wireless Video Transmitter Receiver 8 Channels Long Range
4W 300Mhz Wireless Video Transmitter Receiver 8 Channels Long Range
4W 300Mhz Wireless Video Transmitter Receiver 8 Channels Long Range
4W 300Mhz Wireless Video Transmitter Receiver 8 Channels Long Range
4W 300Mhz Wireless Video Transmitter Receiver 8 Channels Long Range
4W 300Mhz Wireless Video Transmitter Receiver 8 Channels Long Range
4W 300Mhz Wireless Video Transmitter Receiver 8 Channels Long Range
4W 300Mhz Wireless Video Transmitter Receiver 8 Channels Long Range
4W 300Mhz Wireless Video Transmitter Receiver 8 Channels Long Range
4W 300Mhz Wireless Video Transmitter Receiver 8 Channels Long Range
Specifications
Place of Origin :
China
Brand Name :
Kimpok technology
Model Number :
KP-300VTX4W
Price :
Negotiation
Certification :
CE Cerfication
MOQ :
1 pieces
Payment Terms :
T/T, Western Union, PayPal
Supply Ability :
5000pcs/month
Delivery Time :
3-7 work days
Packaging Details :
International standard packing
Type :
wireless video transmission
Frequency :
300Mhz
Modulation :
FM
RF power :
4W
Channel :
8 Channels
Dimensions :
64*46*20mm (antenna port not included)
Description

FPV 300Mhz 4W Wireless Video Transmitter Receiver 8 Channels Long Range

Description:

This is a new wireless video transmission equipment, which adopts FM modulation mode and a new frequency, avoiding the standard frequency of 1.2Ghz/1.5Ghz/2.4Ghz wireless transmission that has been used more in the same range, and is more suitable for use in complex environments. The receiver sensitivity is -85dBm, and the transmission image is clear and stable. With a ground high-gain antenna, it can transmit 1~2km in the open area of the city, and about 40km in the air-to-ground LOS with high gain antenna (Note:the transmission distance is different in different environments, and the specific transmission distance depends on the actual working environment).

FPV VTX Specification:

Product name

Analog video transmitter

Voltage

DC 12V

Current

600mA

Modulation

FM

Frequency

300Mhz~1Ghz (optional)

Channels

8 channels

Frequency band

320Mhz, 340Mhz, 360Mhz, 380Mhz (customization)

Transmit Power

4 watt

Video Output

1 Vp-p(FM)

Temperature

-10℃ ~ +50℃

Antenna port

SMA female

Transmitter Weight

83g

Dimensions

64*46*20mm (antenna port not included)

VRX Specification:

Product

Analog video receiver

Voltage

DC 12V

Receiving sensitivity

-85dBm

Modulation

FM

Frequency

300Mhz~1Ghz (optional)

Channels

8 channels

Frequency band

320Mhz, 340Mhz, 360Mhz, 380Mhz(customization)

Video Output

1 Vp-p(FM)

Temperature

-10℃ ~ +50℃

Antenna port

SMA female

Transmitter Weight

83g

Dimensions

83*68*15mm (antenna port not included)
