4.9G-5.9G (Including 5.8G) High-Frequency Wireless Receiver Module VRX

Product Overview

This Diamond 6dBi 5.8G Mushroom Head Antenna is a high-performance, omnidirectional antenna designed for 5.8G FPV (First Person View) systems. It operates within a frequency range of 4880-6055MHz. The antenna uses RHCP (Right-Hand Circular Polarization), which effectively reduces multipath interference and provides more stable and reliable video transmission. Its 6dBi high-gain and omnidirectional radiation pattern ensures excellent performance across a wide reception area. The antenna is 150mm tall , features an SMA-J connector , and has a maximum power handling of 50W

Key Features

•


  Wide Frequency Range: Works across a wide frequency range from 4880-6055MHz, making it compatible with various 5.8G devices.




•


  High Gain: The 6dBi high-gain design helps extend signal transmission distance and improve stability.




•


  Omnidirectional Radiation: The omnidirectional radiation pattern ensures wide signal coverage without directional limitations.




•


  RHCP Polarization: Utilizes RHCP polarization to effectively suppress signal reflections and reduce interference.




•


  High Power Handling: Capable of handling a maximum power of 50W, suitable for high-power video transmitters.




Advantages

• Stable Signal: The combination of high gain and RHCP polarization significantly improves signal stability and anti-interference capabilities, providing a more reliable video transmission for FPV flights.

•


  Easy to Install: The standard SMA-J connector and moderate height allow for easy installation on various drones, video transmission modules, or FPV goggles.




•


  Reliable Performance: A Voltage Standing Wave Ratio (VSWR) of less than 1.8 ensures good impedance matching between the antenna and the RF module, minimizing signal loss.




Applications

• FPV Drones: Can be used as a video transmitter or receiver antenna on drones to increase transmission range and stability.

• Video Transmission Systems: Suitable for various 5.8G wireless video transmission systems, such as for surveillance or reconnaissance.

• RC Models: Can serve as a receiver antenna for RC models, improving the reliability of control signals.

• FPV Goggles/Displays: Can be connected to FPV goggles or displays to receive video signals from a drone.

Specification Table
