Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards
Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards
Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards
Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards
Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards
Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards
Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards
Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards
Specifications
Apparent Porosity :
18
Thermalconductivity :
0.11 to 0.16 W/m·K
Brand Name :
RONGSHENG
Width :
610mm to 1220mm
Color :
White to Off-white
Installation :
Easy to cut and install
Place of Origin :
Henan, China
Grade :
COM (Common)
Thermal Conductivity :
0.055-0.180(W.k.m.)
Fire Resistance :
Non-combustible
Fiber Diameter :
20mm 30mm 50mm
Oem Odm :
YES
Size :
Customizable
Certification :
ISO9001
Refractory Temperature :
1260℃
Chemicalresistance :
Good resistance to most chemicals
Chemical Resistance :
Excellent
Chemical Composition :
AL2O3
Description

Ceramic Fiber Board Advantage:



1, with high temperature thermal conductivity, light weight, long life, tensile strength, good elasticity, non-toxic and so on.
2, high compressive strength, long service life;
3, low heat capacity, low thermal conductivity;
4, non-brittle material, good toughness;
5, the size of accurate, good flatness;
6, easy to install,
7, excellent anti-wind erosion performance;
8, continuous production, fiber distribution, performance and stability;
9, excellent sound and noise reduction performance.
Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards
Specification
Type
COM
ST
HP
HA
Zir-Alu
HZ
Classified Temp.
1100ºC
(1983ºF)
1260ºC
(2300ºF)
1260ºC
(2300ºF)
1360ºC
(2480ºF)
1400ºC
(2550ºF)
1430ºC
(2600ºF)
Working Temp.
<1000ºC
(2012ºF)
1050ºC
(1922ºF)
1100ºC
(2012ºF)
1200ºC
(2192ºF)
1200ºC
(1192ºF)
1350ºC
(2462ºF)
Color
white
white
white
white
white
white
Density(kg/m3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
260-320
(16-20lb/ft3)
Linear Shrinkage (%)
(24 hrs)
-3
(1000ºC/1832ºF)
-3
(1000ºC/1832ºF)
-3
(1100ºC/2012ºF)
-3
(1250ºC/2282ºF)
-3
(1000ºC/2012ºF)
-3
(1350ºC/2462ºF)



Thermal conductivity
(W/M.K)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
0.085
(400ºC/752ºF)
0.132
(800ºC/1472ºF)
0.180
(1000ºC/2012ºF)
Compression Strength
(Mpa)
0.5
0.5
0.5
0.5
0.5
0.5

Chemical(%)
Al2O3
44
46
47-49
52-55
45-46
39-40
Al2O3+SiO2
96
97
99
99
-
-
Al2O3+SiO2+ZrO2
-
-
-
-

99
ZrO2
-
-
-
-
.5-7
15-17
Fe2O3
<1.2
<1.0
0.2
0.2
0.2
0.2
Na2O+K2O
≤0.5
≤0.5
0.2
0.2
0.2
0.2
Size(mm)
1200*1000mm(47″*40″); 1000*600mm(40″*36″);900*600mm(24″*36″)
20-50mm(1″/2″)thickness
Furnace Kiln Boiler Refractory Materials Ceramic Fibre Board 1260C 1430C Aluminum Silicate Insulation Boards
Product Application

Fire resistant ceramic fiber board applications:


1.Industrial kiln wall lining, masonry insulation layer, high temperature, high heat equipment insulation, insulation, high temperature kiln kiln lining, kiln car, door baffle, furnace furnace temperature divider, aerospace, shipbuilding insulation, Fireproof, soundproof, insulated. 2.Iron and steel industry: expansion joints, insulation, insulation and insulation; non-ferrous metal industry: backing insulation materials, tundish and tank cover for pouring copper and copper alloy; 3.Ceramic industry: light kiln car structure and the furnace hot surface lining, the furnace temperature zone separation and fire materials; Glass industry: the pool was lining heat, burner block; 4.Furnace building: hot surface refractories (alternative fiber blanket), heavy refractory lining, expansion joints; 5.Light industry: lining of industrial and domestic boiler combustors; 6.Petrochemical industry: high temperature heating furnace lining hot surface material; 7.Building materials industry: cement rotary kiln and other equipment insulation.
