Specifications
MOQ :
1 Ton
Bulk Density :
3.4 - 3.6 g/cm³
Productname :
Magnesia Bricks
Lace Of Origin :
Henan, China
Chemical Composition :
MgO ≥ 85%
Certification :
ISO9001
Maximum Service Temperature :
1600 - 1800°C
Color :
White to light gray
Brand Name :
RONGSHENG
Compressive Strength :
≥50 MPa
Efractoriness :
1450
Thermal Conductivity :
2.5 - 3.0 W/m·K
Place of Origin :
Henan, China
Alkaline Resistance :
Excellent
Type :
Refractory Brick
Acid Resistance :
High
Size :
230 x 114 x 65 mm (typical)
Manufacturing Process :
Sintered
Keyword :
Magnesia Brick
Description

Product Description:

Magnesia calcium brick is made of high-quality dolomite and magnesite as raw materials by light firing ingredients, pressing balls and high temperature firing, and the MgO/CaO ratio is selected according to different needs for the production of stereotyped magnesium-calcium refractory materials.

Magnesia calcium brick is also known as high calcium magnesia brick. Magnesia refractory with magnesia as the main crystal phase and tricalcium silicate as the secondary crystal phase. Using calcium magnesia as raw material, after crushing, batching, mixing and molding, it is fired at a high temperature of 1550~1600 °C.

Product Advantages:

Good high-temperature performance, with a starting temperature of load softening generally higher than 1700 ℃, and good resistance to alkaline slag.It has desulfurization effect in molten steel smelting, does not pollute the molten steel, and is easy to remove impurities in the molten steel, which is conducive to the production of clean steel.

High Quality 75% MgO Dolomite Bricks Fused Magnesia Calcium Refractory Bricks For Steel Ladles

Specification

Magnesia Calcium Brick Technique Data

Item Specification
MG20 MG30 MG40 MG50
CaO % ≥18 ≥28 ≥38 ≥48
MgO+CaO % ≥94
SiO2+Al2O3+Fe2O3 % ≤2.5
Apparent Porosity % ≤15
Bulk Density g/cm3 ≥2.95 ≥2.9
CCS MPa ≥60
0.2MPa RUL, ℃ ≥1700
Application

Magnesia Calcium Brick Application:

Suitable for refining devices such as AOD furnaces and VOD furnaces, as well as cement kilns, blast holes of steelmaking side blown converters, top of open hearth furnaces and oxygen blown converters, permanent layers of steelmaking converters, furnace bottoms, and steel ladles.

High Quality 75% MgO Dolomite Bricks Fused Magnesia Calcium Refractory Bricks For Steel Ladles

Packaging & Shipping

The bricks are packed on wooden pallet with papers in each layer and PP film wrapped outside of the whole pallet.

High Quality 75% MgO Dolomite Bricks Fused Magnesia Calcium Refractory Bricks For Steel Ladles

Company Information

ZHENGZHOU RONGSHENG REFRACTORY CO., LIMITED has 30 years of experience in R & D and design of unshape refractory experts, holds 20 utility model patents and 7 invention patents, and has passed the ISO quality, environment and safety management system certification. The company is committed to the R & D, production and service of refractories used in metallurgy, electric power, nonferrous metals, building materials, chemical industry and other industries. Its products cover 198 kinds of materials and 2369 varieties in three categories (acidic, neutral and alkaline), providing overall solutions for refractories for 1200 domestic and 200 foreign customers.The products are mainly all kinds of stereotyped and amorphous refractories, with full refractory physical and chemical index testing equipment and testing system, through ISO quality, environment, safety three management systems.
