• Output mode: Constant voltage
• Input: AC100-240Vac, 50/60Hz or 220-240Vac, 50/60Hz
• Protections: Short circuit, current, and voltage protection
• Energy Efficiency: Compliant with DOE, CEC, ERPII MEPS GEMS standards
• AC inlet: C8/C6/C14/Fixed
• Working environment: 0-40℃, 5%-95% RH

FQA

Q1: What are the output parameters of this 90W desktop adapter?
A: Constant‑voltage output, regional max power 100W, DC 5‑36V, 0.01‑8.33A, universal AC input 100‑240Vac 50/60Hz, typical rated output 24V 3.75A.
Q2: What safety protection features are built‑in?
A: Automatic short‑circuit, over‑current and over‑voltage protection to protect end devices from power‑caused damage.
Q3: What global certifications does this power adapter possess?
A: UL, cUL, FCC, GS, CCC, CQC, KC, PSE, UKCA, SAA, RCM, RoHS, CB and other regional safety approvals.
Q4: What AC inlet types are optional?
A: C8, C6, C14 and fixed‑type AC inlet for different device integration requirements.
Q5: What AC and DC plug options are offered?
A: AC plugs for US, EU, UK, AU, KR, JP, CN, Brazil, India, Argentina and more. Multiple standard DC plugs available, custom DC connectors are supported.
Q6: Which energy‑efficiency standards does it comply with?
A: Compliant with DOE, CEC, ErP II, MEPS, GEMS international energy‑efficiency regulations.
Q7: What is the operating environment requirement?
A: Operating temperature 0‑40℃, relative humidity 5%‑95% RH.
Q8: What safety standards is this adapter designed according to?
A: Developed per EN62368/UL 1310, EN61558 and corresponding Chinese national safety standards.
Q9: What devices can this 24V 3.75A 90W adapter power?
A: Suitable for various 24V indoor constant‑voltage electronics including LED lights, security equipment, network terminals, audio‑visual hardware and other devices within 90W power rating.
Q10: Do you support OEM & ODM customization?
A: Yes, OEM and ODM services with custom labeling, packaging and housing modifications are available upon request.

Why choose us?

• AC plugs available: US, EU, UK, AU, Korea, Japan, China, Brazil, India, Argentina and others
• DC plug options: 5.5*2.1/5.5*2.5/4.0*1.7/3.5*1.35/2.5*0.7/XLR/
