60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
Specifications
Place of Origin :
Guangdong, China
Brand Name :
KSPOWER
Model Number :
KSHT-60W
Certification :
UL/cUL Class2 CE FCC GS ENEC ROHS
MOQ :
100 pieces
Price :
$25.10/pieces 100-499 pieces
Warranty(Year) :
5-Year
Lighting solutions service :
Lighting and circuitry design
Output Power :
60W
Output Type :
PWM
Input Voltage :
100-277V
Output Frequency :
50/60Hz
Output Current :
2.5A
Product Name :
60 Watts Waterproof Converter Transformer Power Supply 12V 24V 36V 48V
Output :
12V/24V/36V/48V
IP Rate :
IP65,IP67
Application :
LED Lighting
Efficiency :
≥ 88%
Warranty :
5 Years
Color :
White Black
Material :
Aluminium Case
Dimming mode :
Triac / Phase-cut Dimmable
Description
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
Products Description
Phase cut Dimming LED Driver 60 Watts Waterproof Converter Transformer Power Supply 12V 24V 36V 48V for Outdoor LED Light
The KSPOWER - HT series phase cut dimmable led driver 60 Watt is one constant voltage solution, accept universal AC input voltage range from 100V to 277V, output voltage 12Volt 24Volt 36Volt 48Volt optional with greater operating efficiency and PFC function. The phase dimming led power supply use low profile metal aluminum case with or without junction box makes the ac dimmable led power supply solutions for LED strips, LED sign, billboard and landscape lighting. Featuring 10K frequency PWM output and IP67 rated waterproof environment protection rated for indoor or outdoor use, the led lights power supply provide 5 years warranty and outstanding led dimming performance.
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
Features:
* Input Voltage: Universal 100VAC to 277VAC, 50/60Hz for Residential, Commercial, and Industrial Use
* Single Channel & Constant Voltage mode
* Output Voltage: 12Volt/24Volt/36Volt/48Volt
* Driver Type: Class 2 Class P
* Enclosure:LISTED Enclosure with Junction Box / LISTED Enclosure without Junction Box
* Dimming: TRIAC or MLV / ELV Phase Dimmable Available
* Environmental: Dry and Damp
* Wiring Compartments with Knock-Outs for Clean and Easy Installation
* Current Limiting Overload Protection
* Flicker-Free
* Smooth Ripple Free Output Voltage
* IP67 Rated Enclosure for Indoor and Outdoor Use
* 5-Years Warranty
* UL/cUL CE FCC RoHS ENEC GS Listed, SELV, Type HL

Note:Any custom label/package/case is acceptable, provide OEM and ODM service
Input Voltage
100~277V AC 47~63Hz
Power Factor
PF≧0 98/115VAC, PF≧0 95/230VAC, PF≧0.9/277VAC, 80% with load
NO.
KSHT-60W12
KSHT-60W24
KSHT-60W36
KSHT-60W48
Output Voltage
12V
24V
36V
48V
Rated Current
5A
2.5A
1.67A
1.25A
Rated Power
60W
Ripple & Noise (max.)
200mVp-p
250mVp-p
250mVp-p
250mVp-p
Dimension(L*W*H)
188*58*36mm / 7.4*2.3*1.4 inch
Show Details
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
Dimming Connect Drawing
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
Dimension Drawing
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
Product packaging
1. Each one put in one small inner brown box, then 20 pcs put in one standard carton.
2. Sample is available.
3. Shipping method: available for express DHL/UPS/FedEx/TNT, Land, Ocean and others
Package
Piece/Carton(pcs)
Piece Weight(KG)
OEM package
20
0.84
Dimension/Brown Box(mm)
Dimension/Carton(mm)
Gross Weight/Carton(KG)
313*64*40
355*330*195
17.5
Applications
60W Triac Dimmable Driver PWM Phase Cut Waterproof LED Driver For Outdoor
Company Profile
Shenzhensshi Zhenhuan Electronic Co., Ltd and Shenzhen Keysun Technology Limited.
We’re an enterprise integrating industry and trade, which was founded in 2008, located in Shenzhen. Specializing in R&D, production and sales of AC DC adapter, Power Supply Units, LED driver and Li-ion battery charger, with more than 15 years of experience.

As a strength manufacturer, we have two factories in Shenzhen and Dongguan. We focus on finished product assembly and plug-in semi-finished product processing respectively. At present, we have more than 100 workers and a production area of 3,000 square meters.

We have our own brand--KSPOWER. Brand concept is “ Concentrate on doing one thing well and provide customers with a competitive and reliable products
