24V96W Class 2 LED Power Supply with 100-277V Input for Outdoor LED Strips
24V96W Class 2 LED Power Supply with 100-277V Input for Outdoor LED Strips
24V96W Class 2 LED Power Supply with 100-277V Input for Outdoor LED Strips
24V96W Class 2 LED Power Supply with 100-277V Input for Outdoor LED Strips
24V96W Class 2 LED Power Supply with 100-277V Input for Outdoor LED Strips
24V96W Class 2 LED Power Supply with 100-277V Input for Outdoor LED Strips
24V96W Class 2 LED Power Supply with 100-277V Input for Outdoor LED Strips
24V96W Class 2 LED Power Supply with 100-277V Input for Outdoor LED Strips
24V96W Class 2 LED Power Supply with 100-277V Input for Outdoor LED Strips
24V96W Class 2 LED Power Supply with 100-277V Input for Outdoor LED Strips
Specifications
Lighting solutions service :
Lighting and circuitry design
Brand Name :
KSPOWER
Model Number :
KS-96LW-xx
Certification :
UL/cUL Class2 FCC CE GS ENEC ROHS etc.
Place of Origin :
Guangdong, China
MOQ :
2 pieces
Price :
The price is negotiable
Payment Terms :
T/T
Supply Ability :
300000pcs/monthly
Delivery Time :
20-25 days
Packaging Details :
Brown box and Carton
Application :
LED Strip Light,Pendants, Linears,Cove Lights
Efficiency :
≥89%
Output Frequency :
50/60Hz
Output :
12V24V36V48V
Output Power :
40W / 60W / 80W /100W
Input Voltage :
100-277V
Warranty :
5 years
Material :
Aluminum Case
IP Rate :
IP65
Warranty(Year) :
5-Year
Output Type :
Single Phase
Protection :
OCP, OVP, SCP, OTP
Description
24V96W Class 2 Waterproof LED Power Supply, Non-Dimmable for Outdoor LED Strips
The KSPOWER - L series Non-dimmable LED driver is a constant voltage solution with single channel operation. It accepts universal AC input voltage ranging from 100V to 277V, with optional output voltages of 12V, 24V, 36V, or 48V. Featuring high operating efficiency and PFC function, this Class P dimming power supply uses a low-profile metal aluminum case suitable for dry and damp environments, making it ideal for LED strips, signage, billboards, and landscape lighting.
24V96W Class 2 LED Power Supply with 100-277V Input for Outdoor LED Strips
Key Features
  • Input Voltage: Universal 100VAC to 277VAC, 50/60Hz for Residential, Commercial, and Industrial Use
  • Single Channel & Constant Voltage mode
  • Output Voltage: 12V/24V/36V/48V
  • Driver Type: Class 2 Class P
  • Enclosure: LISTED Enclosure with input and output wire
  • Environmental: Dry and Damp
  • Wiring Compartments with Knock-Outs for Clean and Easy Installation
  • Current Limiting Overload Protection
  • Flicker-Free Operation
  • Smooth Ripple Free Output Voltage
  • IP67 Rated Enclosure for Indoor and Outdoor Use
  • 5-Year Warranty
  • UL/cUL CE FCC RoHS ENEC GS Listed, SELV, Type HL

FQA

1.Q: Do your drivers have UL/cUL certification? How long is the warranty?
A: Our products are UL/cUL listed, and we provide 5-year warranty.


2.Q: Can this power driver be used indoors and outdoors?
A: Yes.,It reaches IP65 waterproof rating, suitable for indoor and outdoor applications.


3.Q: Are all goods tested before shipment?
A: All units are 100% burn-in tested to guarantee stable performance.


Why choose us?


.Triac/0-10V/1-10V/10V PWM/Resistance dimming/Non-dimming,multiple dimmable function combinations are available


.Suitable for forward & reverse phase dimming(MLV/ELV)


.Slim shape,suitable for tighter spaces


.Input voltage 100-277V,12V24V36V48V output voltage optional,and 30-100W power range


.Glue filling process,heat dissipation,waterproof and moisture-proof


.High efficiency and energy saving,high PFC,flicker-free


.Approved UL/cUL Class2 FCC CE GS ENEC RoHS cert


24V96W Class 2 LED Power Supply with 100-277V Input for Outdoor LED Strips
Technical Specifications
Dimming Type Series Power Model (xx=output voltage) Output voltage Output current Input voltage Size
Non-Dimming L 30W KS-30LW-xx 12V24V36V48V 2.5A | 1.25A | 0.83A | 0.62A 100~277V 50/60Hz 270*32*24.5mm
40W KS-40LW-xx 12V24V36V48V 3.33A | 1.66A | 1.11A | 0.83A
Non-Dimming L 60W KS-60LW-xx 12V24V36V48V 5A | 2.5A | 1.66A | 1.25A 310*32*24.5mm
80W KS-80LW-xx 12V24V36V48V 6.66A | 3.33A | 2.22A | 1.66A
Non-Dimming L 96W KS-96LW-24 24V / | 4A | / | / 355*32*24.5mm
100W KS-100LW-xx 12V24V36V48V 8.33A | 4.16A | 2.78A | 2.08A
Note: Custom labeling, packaging, and cases are available. OEM and ODM services provided.
