Specifications
Power consumption :
≤5VA
Switch quantities inputt :
2~4CH can be optional, present is under IO status
Alarm type :
Upper and lower alarm output with 4 mode, 2 uppers and 2 lowers
Open hole size :
92*92mm
Brand Name :
TOPRIE
Model Number :
TP740
Certification :
CE ROHS
Place of Origin :
China
MOQ :
1 piece
Price :
USD 245.00 ~USD 520.00
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
100 pieces per day
Delivery Time :
5-8 work days
Packaging Details :
packed in paper carton
Storage :
8GB built-in TF card
Wireless communication :
4G,WiFi,LoRa or Thread optional
Dimension :
96*96*102mm
Numbers of channel :
8CH universal input,4CH switch quantities /pulse sampling input,4CH relay output
Record interval :
1-9999s
Operation environment :
-20℃~60℃ 0~95%RH No condensing
Record mode :
Loop record
Wired communication :
RS485 Modbus RTU protocol Ethernet port support Modbus TCP protocol
Material :
Fireproof ABS
Keyword :
Paperless Recorder
Relay :
2~4CH normal open relay 30VDC/1A
Input signal :
Thermocouple, thermal resistor,current and voltage.analog input
Description

Panel Data Acquisition System Smart K Type Temperature Recorder 96*96mm Embedded Panel 8 Channel Paperless Recorder


  • 4" touch screen paperless recorder with 12 channel (8 channel universal input,2-4 channel of pulse input for optional)
  • It supports analog input signal temperature,humidity,current,voltage,pressure,level,flow,displacement etc..
  • Communication: RS485,4G,WiFi, Ethernet,LoRa etc..
  • Certificates CE,ROHS
  • Protocol:Modbus RTU,Modbus TCP
  • Warranty: 12 months
  • Free IoT plaform and mobile APP monitor, support real-time data view,historcial data export CSV,PDF format,alarm information push via email.


Data Acquistion list

Input type

Measuring range

(Indication range)

Measuring accuracy

(quoted error,absoluted error)

 Digit display resolution
DC voltage 0-10V 0V~＋11.000V 0.05%F.S±0.1mV 0.01V
0-5V 0V~＋5.000V 0.05%F.S±0.1mV 0.01V
±20mV -21mV~＋21mV 0.005%F.S±0.005mV 0.01mV
±100mV -110.0mV~＋110.mV 0.005%F.S±0.005mV 0.01mV
DC current 4-20mA ＋3mA~21.00mA 0.005%F.S±0.005mA 0.01mA


Measuring accuracy

(related error) all without even numbers
Themocouple K -60℃~+1372℃ ±0.05%rdg.±2.0℃ 0.01℃
J -100℃~+1200℃ ±0.05%rdg.±2.0℃ 0.01℃
E -100℃~+1000℃ ±0.05%rdg.±2.0℃ 0.01℃
T -100℃~+400℃ ±0.05%rdg.±2.0℃ 0.01℃
N -100℃~+1300℃ ±0.05%rdg.±2.5℃ 0.01℃
W +1500℃~+2315℃ ±0.05%rdg.±3.5℃ 0.01℃

0℃~+1500℃ ±0.05%rdg.±3.0℃ 0.01℃
R +800℃~+1768℃ ±0.05%rdg.±3.0℃ 0.01℃

+400℃~+800℃ ±0..2%rdg.±4.0℃ 0.01℃
S +800℃~+1768℃ ±0.05%rdg.±3.0℃ 0.01℃

+400℃~+800℃ ±0.2%rdg.±2.0℃ 0.01℃
B +800℃~+1820℃ ±0.05%rdg.±3.0℃ 0.01℃

+400℃~+800℃ ±0.2%rdg.±4.0℃ 0.01℃
Thermal resistor PT100 -200℃~+660℃ ±0.05%rdg.±0.4℃ 0.01℃

PT1000 -200℃~+300℃ ±0.05%rdg.±0.4℃ 0.01℃
Warmup time Over 10 minutes
Operation status Temperature:25℃ ±3℃ Humidity: 55%±10% Power supply 8V~28VDC
Environment -20℃~60℃ 0~95%RH no condensing


Application field


TP740 paperless recorder is widely used in all kinds of fields, such as electrical furnace, industrial oven, temperature and humidity test chamber, medical lab, as well as in chemical,pharmacy,food,agriculture and power industries.
