| Zongshen NC 300S engine | |
| Specification | |
| Vehicle Type | Steel and alloy |
| Engine Type | 4 vales,4 stroke, water-cooled,twin-cam |
| Engine Model | NC300S |
| Cylinder Arrangement | Single Cylinder |
| Piston Displacement (cc) | 283cc |
| Maximum Power (kw/r/min) | 23/9500 |
| Maximum Torque (N.m./rpm) | 25/7000 |
| Transmission System | Chain drive |
| Ignition Type | C.D.I |
| Starter System | Electric/Kick |
| Transmission | 6 Speed, International |
| L×W×H (mm) | 2160X830x1300 |
| Wheel Base (mm) | 1460 |
| Seat Height (mm) | 950 |
| Ground Clearance (mm) | 270 |
| Dry Weight (kg) | 108 |
| Brake (Front/Rear) | Disk/Disk |
| Tyre(Wheel rim), Front | 80/100-21(1.60-21) |
| Tyre(Wheel rim), Rear | 100/90-18(2.15-18) |
| Fuel Tank Capacity (L) | 9 |
| Engine Oil Capacity (L) | 1.1 |
| Max. Load Capacity (kg) | 150 |
| Max. Speed(km) | 160 |
| Battery | Lithium cell |
| QTY for loading | 32 PCs /SKD/20GP |
| 105PCs/SKD/40HC | |
