3 Way LTCC Coupler Power Splitter Combiner 1600-2800 MHz 50 Ohm Surface Mount
3 Way LTCC Coupler Power Splitter Combiner 1600-2800 MHz 50 Ohm Surface Mount
Specifications
Certification :
RoHS Compliant
Storage Temperature :
-55°C to 100°C
Model :
JY-SCN-3-28+
Place of Origin :
Shenzhen, Guangdong, China
Package Size :
3.2 x 1.6 mm
Pin Connections :
SUM PORT 2, PORT 1 6, PORT 2 5, PORT 3 4, GROUND 1,3 (PORT 1-2/2-3 resistor external 124 ohms, PORT 1-3 resistor external 127 ohms)
Operating Temperature :
-55°C to 100°C
Frequency Range :
1600-2800 MHz
Brand Name :
JYRF
Impedance :
50 Ohm
RF Power Input :
15 W
Model Number :
JY-SCN-3-28+
Product Type :
3-Way Power Splitter Combiner
Description

JY-SCN-3-28+ 3-Way Power Splitter Combiner 1600-2800 MHz 50 Ohm LTCC Surface Mount

Electrical Specifications

Parameter Frequency (MHz) Min. Typ. Max. Unit
Insertion Loss (above 3.0 dB) 1600-2800 - 0.8 1.2 dB
Isolation 1600-2800 10 12 - dB
Phase Unbalance 1600-2800 - 5.0 8.0 Degree
Amplitude Unbalance 1600-2800 - 0.2 0.6 dB
Return Loss (Input) 1600-2800 10 - - dB
Return Loss (Output) 1600-2800 12 - - dB

Features

  • Isolation resistor, external
  • Low insertion loss
  • Excellent amplitude and phase unbalance
  • High isolation
  • Excellent power handling
  • ESD non-sensitive

Applications

  • GSM
  • ISM
  • Cellular
  • WLAN

Maximum Ratings

Operating Temperature: -55°C to 100°C

Storage Temperature: -55°C to 100°C

RF Power Input: 15 W

Mechanical Dimensions

Package Size: 3.2 x 1.6 mm

Pin Connections

SUM PORT 2, PORT 1 6, PORT 2 5, PORT 3 4, GROUND 1,3 (PORT 1-2/2-3 resistor external 124 ohms, PORT 1-3 resistor external 127 ohms)
