JY-SLP-27+ Low Pass Filter DC-27 MHz 50 Ohm Connectorized Metal Shielded Case
JY-SLP-27+ Low Pass Filter DC-27 MHz 50 Ohm Connectorized Metal Shielded Case
Specifications
Product Type :
Low Pass Filter
Connection :
Connectorized (RF In / RF Out)
Model :
JY-SLP-27+
RF Power Input :
0.5 W max @ 25°C
Impedance :
50 Ohm
Certification :
RoHS Compliant
Place of Origin :
Shenzhen, Guangdong, China
Brand Name :
JYRF
Operating Temperature :
-40°C to 85°C
Frequency Range :
DC-27 MHz
Model Number :
JY-SLP-27+
Cutoff Frequency :
30
Package Size :
18.50 x 7.92 x 56.00 mm Connectorized Shielded Case (54.0 g)
Storage Temperature :
-55°C to 100°C
Description

Electrical Specifications

Parameter Frequency (MHz) Min. Typ. Max. Unit
Pass Band DC-27 MHz - - - MHz
Insertion Loss DC-27 MHz - 0.5 1.0 dB
Cutoff Frequency (3 dB) - - 30 - MHz
VSWR (Passband) DC-27 MHz - 1.2 1.6 :1
Stop Band, Rejection 36-41 20 26 - dB
Stop Band, Rejection 41-810 37 43 - dB

Features

  • low insertion loss, 0.5 dB typ
  • high rejection, 43 dB typ
  • good VSWR, 1.2:1 typical in passband
  • sharp cut-off
  • rugged shielded case
  • connectorized package

Applications

  • defense communications
  • transmitters / receivers
  • harmonic rejection

Maximum Ratings

Operating Temperature: -40°C to 85°C

Storage Temperature: -55°C to 100°C

RF Power Input: 0.5 W max @ 25°C

Mechanical Dimensions

Package Size: 18.50 x 7.92 x 56.00 mm Connectorized Shielded Case (54.0 g)

Connections

Connectorized package (RF In / RF Out, see electrical schematic)
