Description
DM 200 Five-Axis CNC Tool Grinder

DM 200 five-axis CNC tool grinder is developed for tool production as well as resharpening. The machine tool is an iron casting based and rigid machine, in which the X, Y, Z is linear axis and the A, C are rotating axis with the application of GSYun. It is specialized in the production of standard mills varied, drill bits, reamers, non-standard cutters, and other cutting tools, with high efficiency, high precision. In high-speed steel, cemented carbide tool manufacturing field it has extraordinary advantages.

Technical Specifications
Model DM-200
1 X axis travel 800mm
2 Y axis travel 400mm
3 Z axis travel 220mm
4 A axis travel Consecutive 360°
5 C axis travel 220°
6 X axis positioning accuracy 0.005mm
7 Y axis positioning accuracy 0.005mm
8 Z axis positioning accuracy 0.005mm
9 A axis positioning accuracy 0.005°
10 C axis positioning accuracy 0.005°
11 Repeat positioning accuracy ± 0.002 mm
12 Minimum units 0.01°
13 Spindle rated power 12 KW; torque 20 NM;
(double extension spindle)
14 Speed of main shaft 0 - 8000 RPM/min
15 Number of grind wheels installed 6 - 8 pieces
16 Maximum wheel diameter Φ150mm
17 Diameter of Grinding Wheel Rod HSK50E
18 Taper of workpiece shank BT50
19 Maximum grinding length Blade length: 160 mm;
Total Length: 200 mm
20 Minimum handle diameter Φ3mm
21 Maximum workpiece shank diameter Φ20mm
22 Maximum length of workpiece Φ200mm
23 Working pressure 0.6 ~ 0.8 MPa
24 Cooling fluid flow 85L/min
25 Total rated power of equipment 22 kw
(three – phase AC 380V)
26 Total equipment weight 5000 kg
