DIN 11850 Food Grade 28mm OD Stainless Steel Tube , 316L Food Grade SS Pipe
DIN 11850 Food Grade 28mm OD Stainless Steel Tube , 316L Food Grade SS Pipe
DIN 11850 Food Grade 28mm OD Stainless Steel Tube , 316L Food Grade SS Pipe
DIN 11850 Food Grade 28mm OD Stainless Steel Tube , 316L Food Grade SS Pipe
DIN 11850 Food Grade 28mm OD Stainless Steel Tube , 316L Food Grade SS Pipe
DIN 11850 Food Grade 28mm OD Stainless Steel Tube , 316L Food Grade SS Pipe
Specifications
Brand Name :
SINOSTEEL
Model Number :
316L
Certification :
ISO
Place of Origin :
MADE IN CHINA
MOQ :
negotiation
Price :
negotiation
Payment Terms :
20% T/T at PO, 80% before shipment
Supply Ability :
200T
Delivery Time :
about 4 weeks
Packaging Details :
Packed in wooden boxes
Description :
Stainless steel tube
Grade :
316L
Outer Diameter :
10mm~200mm
Standard :
DIN11850
Wall Thickness :
1mm
Length :
As per request
Application :
Food industry and Pharmaceutical industry
Shape :
Round tube
Description

DIN 11850 stainless steel tube for food hygiene grade tube grade 316L


Products Range

Series one:

Norminal Diameter(mm) 10 15 20 25 32 40 50
Outer Diameter(mm) 12 18 22 28 34 40 52
Tolerance on OD ±0.1 ±0.11 ±0.14 ±0.17 ±0.2 ±0.26
Wall thickness(mm) 1
Wall tolerance ±0.1

Series two:

Norminal Diameter(mm) 10 15 20 25 32 40 50
Outer Diameter(mm) 13 19 23 29 35 41 53
Tolerance on OD ±0.1 ±0.12 ±0.15 ±0.18 ±0.21 ±0.27
Wall thickness(mm) 1.5
Wall tolerance ±0.15

Calculation for Stainless steel pipe weight

Grade Density(Kg/dm3) Calculation
SUS304 SUS304L 7.93 W=0.02491 t(D-t)
TP304 TP304L 7.90 W=0.02482 t(D-t)
SUS316 SUS316L 8.00 W=0.02513 t(D-t)
TP316 TP316L 8.00 W=0.02513 t(D-t)

Main Application:

  • Food industry
  • Pharmaceutical Industry
  • Some other areas which has requirements on inside bead

DIN 11850 Food Grade 28mm OD Stainless Steel Tube , 316L Food Grade SS PipeDIN 11850 Food Grade 28mm OD Stainless Steel Tube , 316L Food Grade SS Pipe
