1.20 - 14.20mm Wall 5 Inch Stainless Steel Tubing , Durable 321 Stainless Pipe
1.20 - 14.20mm Wall 5 Inch Stainless Steel Tubing , Durable 321 Stainless Pipe
1.20 - 14.20mm Wall 5 Inch Stainless Steel Tubing , Durable 321 Stainless Pipe
1.20 - 14.20mm Wall 5 Inch Stainless Steel Tubing , Durable 321 Stainless Pipe
1.20 - 14.20mm Wall 5 Inch Stainless Steel Tubing , Durable 321 Stainless Pipe
1.20 - 14.20mm Wall 5 Inch Stainless Steel Tubing , Durable 321 Stainless Pipe
Specifications
Brand Name :
JUYE
Model Number :
321
Certification :
ISO
Place of Origin :
Made in CHINA
MOQ :
negotiation
Price :
negotiation
Payment Terms :
20% T/T at PO, 80% before shipment or by irrevocable L/C at sight
Supply Ability :
800T
Delivery Time :
within 4 weeks
Packaging Details :
Export package
Description :
Stainless steel welded pipe
Grade :
321
Gauge :
13.50-410mm
Wall thickness :
1.20-14.20mm
Standard :
EN10217-7:2005
Length :
As per request
Application :
Industrial Liquid Pipe
Description

Quick Detail:

Description: Stainless steel welded pipe

Grade: 321

Standard: EN10217-7:2005

Gauge:13.50-410mm

Wall thickness:1.20-14.20mm

Size: see here below attached table "size range"

Size Range

Gauge(mm) Nominal Wall Thickness(mm)
1.20 1.60 2.00 2.30 2.60 2.90 3.20 3.60 4.00 4.50 5.00 5.60 6.30 7.10 8.00 8.80 10.00
13.5 ● ● ● ●
17.2 ● ● ● ●
21.3 ● ● ● ● ●
26.9 ● ● ● ● ● ●
33.7 ● ● ● ● ● ● ●
42.4 ● ● ● ● ● ● ● ●
48.3 ● ● ● ● ● ● ● ● ●
60.3 ● ● ● ● ● ● ● ●
76.1 ● ● ● ● ● ● ● ● ●
88.9 ● ● ● ● ● ● ● ● ● ●
101.6 ● ● ● ● ● ● ● ● ● ●
114.3 ● ● ● ● ● ● ● ● ● ● ●
139.7 ● ● ● ● ● ● ● ● ● ● ●
168.3 ● ● ● ● ● ● ● ● ● ● ● ●
219.1 ● ● ● ● ● ● ● ● ● ● ● ● ●
273 ● ● ● ● ● ● ● ● ● ● ●
323 ● ● ● ● ● ● ● ●
355.6 ● ● ● ● ● ● ● ● ●
406.4 ● ● ● ● ● ● ● ● ●

Chemical Composition

Standard: EN10217-7

Grade:1.4541

C: 0.08%

Si:1.00%

Mn:2.00%

P:0.045%

S:0.03%

Ni:9%~13%

Cr:17%~19%

Ti:5*C%

Mechanical Characteristics

EN10217-7 Grade Yield Strength Tensile Strength Elongation Hardness
N/mm2 N/mm2 % HRB
1.4541 ≥205 ≥520 ≥40 ≤90

Advantage of Stainless Steel Fluid Pipe

The stainless steel fluid pipe is safe, reliable, sanitary, environmental friendly, economical and applicable. The pipe wall is thin, and the connection method is simple and convenient

Main Application:

  • Petrochemical
  • Papermaking
  • Energy
  • Steam
  • Sewage Engineering
