304H Stainless Steel Wire , Diameter Φ5mm - Φ38mm Soft Stainless Steel Wire
304H Stainless Steel Wire , Diameter Φ5mm - Φ38mm Soft Stainless Steel Wire
304H Stainless Steel Wire , Diameter Φ5mm - Φ38mm Soft Stainless Steel Wire
304H Stainless Steel Wire , Diameter Φ5mm - Φ38mm Soft Stainless Steel Wire
Specifications
Brand Name :
Tsingshan
Model Number :
304H
Certification :
ISO9001 ISO14001
Place of Origin :
Made in CHINA
MOQ :
negotiation
Price :
negotiation
Payment Terms :
By T/T or by L/C
Supply Ability :
5000T per month
Delivery Time :
from 3-6 weeks
Packaging Details :
Standard packaging
Description :
Stainless steel rod
Grade :
Grade A
Diameter :
5mm~38mm
Application :
metal line and Cold heading
Shipping terms :
CIF FOB CFR
Coil weight :
500kg~2500kg
Country of origin :
Made in China
Standard :
JIS G4303 JIS G4311 ASTM A959 EN10088-3
Description

304H stainless steel wire rods for hardware wire diameter Φ5mm~Φ38mm

Material

Grade Standards
GB/T 20878-2007 JIS G4303:2005 ASTM A959-09 EN 10088-3:2005
304H 07Cr19Ni10 SUH304H S30409 1.4948

Main Specification:

Description:Stainless steel rod

Grade:304H

Diameter: 5mm,5.5mm,6mm,5mm,7mm,7.5mm,8mm,8.5mm,9mm,9.5mm,10mm,11mm,11.5mm,12mm,13mm,15mm,16mm,17mm,18mm,19mm,20mm,21mm,22mm,23mm,24mm,25mm,26mm,28mm,30mm,32mm,34mm,38mm

Coil weight: 500kg~2500kg

Dimensional Tolerance: Grade A,Grade B,Grade C

Length:Cut to customer needs

Dimensional Tolerances for stainless steel wire rod

Diameter (mm) Tolerance(mm)
Grade A Grade B Grade C
≥5.0~10 ±0.30 ±0.25 ±0.15
>10~15 ±0.40 ±0.30 ±0.20
>15~25 ±0.50 ±0.35 ±0.25
>25~38 ±0.60 ±0.40 ±0.30

OvalityTolerances for stainless steel wire rod

Diameter (mm) Ovality(mm)
Grade A Grade B Grade C
≥5.0~10 ≤0.50 ≤040 ≤0.24
>10~15 ≤0.60 ≤0.48 ≤0.32
>15~25 ≤0.70 ≤0.56 ≤0.40
>25~38 ≤0.96 ≤0.64 ≤0.48

Chemical Composition:

Grade:304H

C:0.04-0.10%

Si:≤1.0%

Mn:≤2.0%

P:≤0.045%

S:≤0.030%

Cr:18%-20%

Ni:8%~11%

Cu:0.50%

N:≤0.15%

Features and Application

Due to high strength, elastic stability, good fatigue resistance, good corrosion resistance in outdoor harsh environment, so it's widely used for making spring, steel strand and cable etc.

304H Stainless Steel Wire , Diameter Φ5mm - Φ38mm Soft Stainless Steel Wire
