Thermal Fatigue Resistant 430 Series Stainless Steel Roll SUS430 1.4016 S43000 Grade
Thermal Fatigue Resistant 430 Series Stainless Steel Roll SUS430 1.4016 S43000 Grade
Specifications
Brand Name :
Baosteel Jisco Yongjin
Model Number :
SUS430 1.4016 S43000
Certification :
ISO9001 14001
Place of Origin :
made in CHINA
MOQ :
negotiation
Price :
negotiation
Payment Terms :
by T/T in advance OR by irrevocable L/C at sight
Supply Ability :
5000T/M
Delivery Time :
around 30dd
Packaging Details :
Standard Export Packing
Grade :
SUS430 1.4016 S43000
Thickness :
0.3-3.0mm
Width :
1000-1550mm
Tolerance for mill edge :
+/-15mm
Country of Origin :
Made in China
Lead time :
30dd
Shipping terms :
EXW FOB CFR CIF
Finish :
NO.1、1D、2D、2B、N0.4、HL、BA、Mirror
Description

1000mm~1550mm 430 cold rolled stainless steel coils SUS430 1.4016 S43000

430 cold rolled stainless steel coils

Quick Detail

  • Description of goods:430 Cold rolled stainless steel coils
  • Grade: SUS430 1.4016 S43000
  • Thickness:0.3-3.0mm
  • Finish: NO.1,1D,2D,2B,N0.4,HL,BA,Mirror
  • Width:1000-1550mm
  • Standard: JIS ASTM AISI ASME EN
  • Coil ID: 508 or 610mm
  • Thickness tolerance:to be defined with customers
  • Surface treatment:Cold rolled,annealed, pickled
  • Coil weight; 8-10MT,9-11MT 4-6MT or as per your request
  • Paper Interleaved: Yes
  • Q'ty tolerance+/-10% on order quantity
  • Edge: MILL/SLIT

CHEMICAL COMPOSITION AND FOR 430

STANDARD GRADE CHEMICAL COMPOSITION(%)
C max Si max Mn max P max S max Ni Cr
JIS SUS430* 0.12 0.75 1.00 0.040 0.030 16.00~18.00
GB 1Cr17 0.12 1.0 1.00 0.040 0.030 0.75 16.00~18.00
ASTM S43000* 0.12 1.0 1.00 0.040 0.030 0.75 16.00~18.00
EN 1.4016 0.08 1.0 1.00 0.040 0.015 16.00~18.00

MECHANICAL PROPERTIES

Material Yield Strength Tensile Strength Elongation Hardness
(N/mm2) (N/mm2) (%) HRB HV
430 ≥205 ≥420 ≥22 ≤80 ≤200

MAIN APPLICATIONS FOR GRADE 430:

430 stainless steel is common-used steel, has good corrosion resistance, has better thermal conductivity than austenitic stainless steel, it’s thermal expansion coefficient is smaller than the austenitic stainless steel, is resistant to thermal fatigue, due to adding stabilized element titanium, has good mechanical properties on welding position.

430 stainless steel is used in building and decoration, household appliances, fuel burner parts,white appliance parts etc.
